VQT1W46
10
Before Use
12 Camera ON/OFF switch (P18)
13 Zoom lever (P33)
14 Speaker (P72)
15 Microphone (P56)
16 Shutter button (P28, 56)
17 Intelligent auto button (P28)
18 Hand strap eyelet
• Be sure to attach the hand strap when
using the camera to ensure that you will
not drop it.
19 Lens barrel
20 [AV OUT/DIGITAL] socket (P83, 86, 90)
21 Tripod receptacle
• When you use a tripod, make sure the
tripod is stable when the camera is
attached to it.
22 Card/Battery door (P14, 15)
23 Release lever (P14)
24 DC coupler cover (P15)
• When using an AC adaptor, ensure that
the Panasonic DC coupler (DMW-DCC4;
optional) and AC adaptor (DMW-AC5G;
optional) are used. For connection details,
refer to P15.
21 22
2324
