Before Use
11 Camera ON/OFF switch (P16)
12 Zoom lever (P30)
13 Speaker (P73)
14 Microphone (P53, 66, 86)
15 Shutter button (P25, 53)
16 Mode dial (P24)
17 Strap eyelet
•
Be sure to attach the strap when using
the camera to ensure that you will not
drop it.
18 Lens barrel
19 [COMPONENT OUT] socket (P95)
20 [AV OUT/DIGITAL] socket (P88, 90, 94)
21 [DC IN] socket (P88, 90)
•
Always use a genuine Panasonic AC
adaptor (DMW-AC5PP; optional).
• This camera cannot charge the battery even when the AC adaptor (DMW-AC5PP;
optional) is connected to it.
22 Tripod receptacle
•
When you use a tripod, make sure the
tripod is stable when the camera is
attached to it.
23 Card/Battery door (P14)
24 Release lever (P14)
11
13
12
14 15 16
