Panasonic DMC-GF3CPP - Page 64

DMC-GF3KEG-K vol.1
Ref.No. Part No. Part Name & DescriptionPc
s
Remarks Ref.No. Part No. Part Name & DescriptionPc
s
Remarks
136-1 VYK5F10 FLASH CASE TOP UNIT 1 (-T) [PAVCSG]
1 VEP56141A MAIN P.C.B. 1 (RTL) E.S.D. 136-1 VYK5F08 FLASH CASE TOP UNIT 1 (-K) [PAVCSG]
EXCEPT EB,EC,EF,EG 137 VMB4520 FLASH LOCK SPRING 1 [PAVCSG]
1 VEP56141B MAIN P.C.B. 1 (RTL) E.S.D. EB,EC,EF,EG 138 VGQ0Y79 FLASH LOCK KNOB 1 [PAVCSG]
2 VGQ0X59 SHEET 1 139 VMP0A29 FLASH LOCK PLATE 1 [PAVCSG]
3 VXQ2130T MOUNT BOX UNIT 1 140 VGQ0W81 FLASH LOCK 1 [PAVCSG]
141 VMP0A28 FLASH LOCK FIX PLATE 1 [PAVCSG]
100 VGK3800 SIDE ORNAMENT (R) 1 (-K,-R,-T) [PAVCSG] 142 VEP50090A POP SW P.C.B. 1 (RTL) [PAVCSG]
100 VGK3801 SIDE ORNAMENT (R) 1 (-W,-P) [PAVCSG] 143 VEE1K47 POP SW HARNESS 1 [PAVCSG]
102 VYK5D69 FRONT CASE UNIT 1 (-K) [PAVCSG] 144 L0CBAY000093 MICROPHONE UNIT 1 [PAVCSG] (M7001)
102 VYK5E77 FRONT CASE UNIT 1 (-W) [PAVCSG]  145 ML-421S/DN BATTERY 1 [ENERGY] (B7001)
102 VYK5E75 FRONT CASE UNIT 1 (-R) [PAVCSG] 146 VEP54027A MAIN-AUDIO FPC UNIT 1 [PAVCSG]
102 VYK5E74 FRONT CASE UNIT 1 (-P) [PAVCSG]
102 VYK5E76 FRONT CASE UNIT 1 (-T) [PAVCSG] B1 VHD2081 SCREW 1 (-W,-P)
102-1 VGK3795 FRONT RING 1 (-K,-R,-T) [PAVCSG] B1 VHD2082 SCREW 1 (-K,-R,-T)
102-1 VGK3796 FRONT RING 1 (-W,-P)[PAVCSG] B2 VHD2081 SCREW 1 (-W,-P)
102-2 VGU0J48 LENS RELEASE BUTTON 1 (-K,-R,-T) [PAVCSG] B2 VHD2082 SCREW 1 (-K,-R,-T)
102-2 VGU0K13 LENS RELEASE BUTTON 1 (-W,-P)[PAVCSG] B3 VHD2081 SCREW 1 (-W,-P)
102-3 VMB4514 LENS RELEASE BUTTON SPRING 1 [PAVCSG] B3 VHD2082 SCREW 1 (-K,-R,-T)
102-4 VMP0A17 LENS RELEASE FIX PLATE 1 [PAVCSG] B4 VHD2081 SCREW 1 (-W,-P)
103 VGK3798 SIDE ORNAMENT (L) 1 (-K,-R,-T) [PAVCSG] B4 VHD2082 SCREW 1 (-K,-R,-T)
103 VGK3799 SIDE ORNAMENT (L) 1 (-W,-P) [PAVCSG] B5 VHD2102 SCREW 1 (-W,-P)
104 VYK5D75 REAR CASE UNIT 1 (-K) [PAVCSG] B5 VHD2103 SCREW 1 (-K,-R,-T)
104 VYK5E93 REAR CASE UNIT 1 (-W) [PAVCSG] B6 VHD2102 SCREW 1 (-W,-P)
104 VYK5E91 REAR CASE UNIT 1 (-R) [PAVCSG] B6 VHD2103 SCREW 1 (-K,-R,-T)
104 VYK5E90 REAR CASE UNIT 1 (-P) [PAVCSG] B7 VHD2102 SCREW 1 (-W,-P)
104 VYK5E92 REAR CASE UNIT 1 (-T) [PAVCSG] B7 VHD2103 SCREW 1 (-K,-R,-T)
105 K0RB00900007 REAR OPERATION UNIT 1 [PAVCSG] B8 VHD2102 SCREW 1 (-W,-P)
106 VGQ0W72 GRIP PIECE REAR 1 (-K,-R,-T) [PAVCSG] B8 VHD2103 SCREW 1 (-K,-R,-T)
106 VGQ0W73 GRIP PIECE REAR 1 (-W,-P) [PAVCSG] B9 VHD2331-A SCREW 1
107 VGQ0W76 LCD FPC TAPE B 1 [PAVCSG] B10 VHD2331-A SCREW 1
108 VMP0A22 REAR PLATE 1 [PAVCSG] B11 VHD2331-A SCREW 1
109 VGQ0Y31 REAR PLATE SHEET 1 [PAVCSG] B12 XQN16+BJ35FN SCREW 1
110 VGQ0Y43 LCD FPC TAPE C 1 [PAVCSG] B13 XQN16+BJ35FN SCREW 1
112 VYK5D76 LCD UNIT 1 [PAVCSG] B14 XQN16+B2FN SCREW 1 [PAVCSG]
112-1 VYK5F22 TOUCH PANEL UNIT 1 [PAVCSG] B100 VHD2332 SCREW 1 [PAVCSG]
113 VGQ0W85 BATTERY CASE 1 [PAVCSG] B101 VHD2332 SCREW 1 [PAVCSG]
114 VMP0A25 BATTERY CASE PLATE 1 [PAVCSG] B102 VHD2332 SCREW 1 [PAVCSG]
115 VMB4516 BATTERY OUT SPRING 1 [PAVCSG] B103 VHD2332 SCREW 1 [PAVCSG]
116 VMB4304 BATTERY LOCK SPRING 1 [PAVCSG] B104 VHD1812 SCREW 1 [PAVCSG]
117 VGU0J96 BATTERY LOCK KNOB 1 [PAVCSG] B105 VHD1812 SCREW 1 [PAVCSG]
118 VMP0A26 TRIPOD 1 [PAVCSG] B106 VHD1812 SCREW 1 [PAVCSG]
119 VGQ0W77 CAPACITOR HOLDER 1 [PAVCSG] B107 VHD2037 SCREW 1 [PAVCSG]
120 VGQ0R70 CAPACITOR TAPE 1 [PAVCSG] B108 VHD2367 SCREW 1 [PAVCSG]
121 VKF4943 JACK DOOR 1 (-W) [PAVCSG] B109 VHD2342 SCREW 1 [PAVCSG]
121 VKF4939 JACK DOOR 1 (-R) [PAVCSG] B110 VHD2342 SCREW 1 [PAVCSG]
121 VKF4941 JACK DOOR 1 (-P) [PAVCSG] B111 VHD2342 SCREW 1 [PAVCSG]
121 VKF4940 JACK DOOR 1 (-T) [PAVCSG] B112 VHD2342 SCREW 1 [PAVCSG]
121 VKF4938 JACK DOOR 1 (-K) [PAVCSG] B113 VHD2342 SCREW 1 [PAVCSG]
 122 VXQ2113 FLASH SUB P.C.B. UNIT 1 [PAVCSG] B114 VHD2342 SCREW 1 [PAVCSG]
123 VMB4515 BATTERY DOOR SPRING 1 [PAVCSG] B115 VHD2342 SCREW 1 [PAVCSG]
124 VMS8186 BATTERY DOOR SHAFT 1 [PAVCSG] B116 VHD2342 SCREW 1 [PAVCSG]
125 VYF3450 BATTERY DOOR UNIT 1 (-W) [PAVCSG] B117 VHD2342 SCREW 1 [PAVCSG]
125 VYF3448 BATTERY DOOR UNIT 1 (-R) [PAVCSG] B118 VHD2342 SCREW 1 [PAVCSG]
125 VYF3447 BATTERY DOOR UNIT 1 (-P) [PAVCSG] B119 XQN16+B2FN SCREW 1 [PAVCSG]
125 VYF3449 BATTERY DOOR UNIT 1 (-T) [PAVCSG] B120 VHD2168 SCREW 1 [PAVCSG]
125 VYF3446 BATTERY DOOR UNIT 1 (-K) [PAVCSG]
126 L0AA01A00105 SPEAKERS 1 [PAVCSG] (SP7001)
127 VMT2027 MIC DAMPER 1 [PAVCSG]
128 VMP0A30 SPEAKER PLATE 1 [PAVCSG]
129 VEP50089A TOP P.C.B. 1 (RTL) [PAVCSG] E.S.D.
130 VMP0A31 TOP PCB PLATE 1 [PAVCSG]
131 VGQ0W83 SPEAKER HOLDER 1 [PAVCSG]
132 VGU0J98 POWER KNOB 1 (-W,-P) [PAVCSG]
132 VGU0J93 POWER KNOB 1 (-K,-R,-T) [PAVCSG]
133 VKW3495 POWER LED PANEL 1 [PAVCSG]
134 VWJ2276 MAIN-TOP FPC 1 [PAVCSG]
135 VYK5F24 TOP CASE UNIT 1 (-W,-P) [PAVCSG]
135 VYK5F23 TOP CASE UNIT 1 (-K,-R,-T) [PAVCSG]
136 VYK5E85 FLASH CASE UNIT 1 (-W) [PAVCSG]
136 VYK5E83 FLASH CASE UNIT 1 (-R) [PAVCSG]
136 VYK5E82 FLASH CASE UNIT 1 (-P) [PAVCSG]
136 VYK5E84 FLASH CASE UNIT 1 (-T) [PAVCSG]
136 VYK5D74 FLASH CASE UNIT 1 (-K) [PAVCSG]
136-1 VYK5F12 FLASH CASE TOP UNIT 1 (-W) [PAVCSG]
136-1 VYK5F09 FLASH CASE TOP UNIT 1 (-R) [PAVCSG]
136-1 VYK5F11 FLASH CASE TOP UNIT 1 (-P) [PAVCSG]
S-13
