Panasonic DMC-LX5 User Manual

11
(ENG) VQT2W84
14 Cursor buttons
15 Aspect ratio selector switch
16 Microphone
17 Zoom lever
18 Motion picture button
19 Flash open switch
20 Hot shoe cover
• Keep the hot shoe cover out of reach
of children to prevent swallowing.
21 Mode dial
22 Shutter button
23 Camera ON/OFF switch
24 [HDMI] socket
25 [AV OUT/DIGITAL] socket
26 Lens ring front
27 Lens barrel
3/[FOCUS] button
4/Function button
Assign Menu to 4 button. It is convenient to register a Menu that is used
often.
[FILM MODE]/[QUALITY]/[METERING MODE]/[WHITE BALANCE]/
[AF MODE]/[I.EXPOSURE]/[GUIDE LINE]/[ REC AREA]/
[REMAINING DISP.]/[FLASH]/[AUTO BRACKET]/[ASPECT BRACKET]
2/Self-timer button
1/ISO
In these operating instructions, the cursor buttons are described as
shown in the figure below or described with 3/4/2/1.
e.g.: When you press the 4 (down) button
or Press 4
15 16 17 18
19 20 21 22 23
24
25
26
27
DMC-LX5PC-VQT2W84_eng.book 11 ページ ２０１０年７月１日 木曜日 午後５時３５分

Panasonic DMC-LX5 Specifications

General

Sensor Type	CCD
Sensor Size	1/1.63 inch
Effective Pixels	10.1 Megapixels
Lens	Leica DC Vario-Summicron
Optical Zoom	3.8x
Focal Length	5.1-19.2mm (24-90mm equivalent)
Aperture Range	f/2.0 - f/3.3
LCD Resolution	460, 000 dots
Video Recording	720p HD
Image Stabilization	Optical
Battery Type	Lithium-Ion
Shutter Speed	60-1/4000 sec
Storage Media	SD/SDHC/SDXC
Video Resolution	1280 x 720
Image Processor	Venus Engine FHD
Battery Model	DMW-BCJ13
ISO Sensitivity	80-12800
LCD Screen	3.0-inch TFT LCD
Weight	271g (with battery and SD card)
