Getting started
- 9 -
1 Disc tray (> 16)
2 Display
3 USB port (> 16)
4 SD card slot (> 16)
5 Remote control signal sensor
Distance: Within approx. 7 m
Angle: Approx. 20e up and down, 30e left and
right
6 V.OFF LED (Video off LED)
It is possible to set the LED to turn on/off.
(> 33)
7 Open or close the disc tray* (> 16)
8 Basic playback control switches* (> 17)
9 Standby/on switch* (Í/I) (> 14)
Touch to switch the unit from on to standby
mode or vice versa. In standby mode, the unit
is still consuming a small amount of power.
* These buttons work just by touching the marks.
When these buttons are touched, the LED will light up.
Rear panel terminals (> 10–13)
1
789
2 3 4 5 6
Pull to flip down
the front panel.
