Connecting to a television and Satellite receiver
To household mains socket
Television’s rear panel
Fully wired 21-pin
Scart cable
(For Q Link functions)
RF coaxial cable
(included, black)
This unit’s rear panel
AC mains lead (included)
Connect only after all other
connections are complete.
To household mains socket
(AC 220 V to 240 V, 50 Hz)
RF coaxial cable
(included)
Fully wired 21-pin
Scart cable
To household mains socket
Satellite receiver’s
rear panel
