Panasonic DP-6030 - Page 521

521
JAN 2006
Ver. 5.2
DP-3510/3520/3530/4510/4520/4530/6010/6020/6030
c. The Swing Guide moves down and, at the same time, the Delivery Roller delivers the sheet.
Fig. 2-030
Offset Sheet
Tray 1/2
Swing Guide
Feed Roller 2
Feed Belts
Stopper
Delivery
Roller
Stapling Tray
