755
JAN 2006
Ver. 5.2
DP-3510/3520/3530/4510/4520/4530/6010/6020/6030
Fig. 2-044
[Paper Folding Start Position]
Fig. 2-045
Folding
Home Position Sensor (PI11
)
Paper Pushing Plate
P
aper Fold Roller (Upper)
Staple/Fold
Motor
M7
Paper Fold Roller (Lower)
Paper stack
Paper Stack
Paper Push Plate
Folds/feeds a paper stac
k.
Inlet
O
utlet
Feeds a paper stack.
