Panasonic DVD S-29 DVD-S29

18
RQT7772
Specifications
Signal system: PAL 625/50, PAL525/60, NTSC
Operating temperature range: i5 to i35 oC
Operating humidity range:
5 to 90 % RH (no condensation)
Discs played (8 cm or 12 cm):
(1) DVD-RAM (DVD-VR compatible, JPEG formatted
discs)
(2) DVD-Video (3)DVD-R (DVD-Video compatible)
(4) CD-Audio (CD-DA) (5)Video CD
(6) SVCD (Conforming to IEC62107)
(7) CD-R/CD-RW (CD-DA, Video-CD, SVCD, MP3,
WMA, JPEG formatted discs)
(8) MP3/WMA
§
≥Compatible compression rate:
MP3: between 32 kbps and 320 kbps
WMA: between 48 kbps and 320 kbps
(9) JPEG
§
≥Exif Ver 2.1 JPEG Baseline files
≥Picture resolution:
between 320k240 and 6144k4096 pixels
(sub sampling is 4:2:2 or 4:2:0)
(10) HighMAT Level 2 (Audio and Image)
Video output:
Output level: 1 Vp-p (75 ≠)
Output terminal:
[The\United\Kingdom\and\Continental\Europe]
Pin jack (1 system)/AV
[Others] Pin jack (1 system)
S-video output:
Y output level: 1 Vp-p (75 ≠)
C output level: NTSC; 0.286 Vp-p (75 ≠)
PAL; 0.300 Vp-p (75 ≠)
Output terminal:
[The\United\Kingdom\and\Continental\Europe] AV
[Others] S terminal (1 system)
Component video output:
[NTSC: 525 (480)p/525 (480)i, PAL: 625 (576)p/625 (576)i]
Y output level: 1 Vp-p (75 ≠)
P
B output level: 0.7 Vp-p (75 ≠)
P
R output level: 0.7 Vp-p (75 ≠)
Output terminal:Pin jack (Y: green, P
B: blue, PR: red)
Number of terminals: 1 system
RGB video output:
[The\United\Kingdom\and\Continental\Europe]
R output level: 0.7 Vp-p (75 ≠)
G
output level: 0.7 Vp-p (75 ≠)
B output level: 0.7 Vp-p (75 ≠)
Output terminal: AV
Audio output:
Output level: 2 Vrms (1 kHz, 0 dB)
Output terminal:
[The\United\Kingdom\and\Continental\Europe]
Pin jack/AV
[Others] Pin jack
Number of terminals: 2 channel: 1 system
Audio performance:
(1) Frequency response:
≥DVD (linear audio):
4 Hz–22 kHz (48 kHz sampling)
4 Hz–44 kHz (96 kHz sampling)
≥CD Audio: 4 Hz–20 kHz
(2) S/N ratio:
≥CD Audio: 115 dB
(3) Dynamic range:
≥DVD (linear audio): 100 dB
≥CD Audio: 98 dB
(4) Total harmonic distortion:
≥CD Audio: 0.0025 %
Digital audio output:
Coaxial digital output: Pin jack
Pickup:
Wave length: 662 nm/785 nm
Laser power: CLASS 2/CLASS 3A
NORSK
Pickup:
Bølgelengde: 662 nm/785 nm
Laserstyrke: Ingen farlig stråling sendes ut
Power supply:
[The\United\Kingdom,\Australia\and]N.Z.]
AC 230–240 V, 50 Hz
[Continental\Europe\and\Russia] AC 230 V, 50 Hz
[Others] AC 220–240 V, 50/60 Hz
Power consumption: 9 W
Power consumption in standby mode
:approx. 1 W
Dimensions (WkDkH): 430 mm k249 mmk52 mm
Mass: 2.4 kg
[Note]
Specifications are subject to change without notice. Mass
and dimensions are approximate.
§
The total combined maximum number of recognizable
audio and picture contents and groups: 4000 audio and
picture contents and 400 groups.
Safety precautions
Set the unit up on an even surface away from direct
sunlight, high temperatures, high humidity, and excessive
vibration. These conditions can damage the cabinet and
other components, thereby shortening the unit’s service
life. Do not place heavy items on the unit.
Do not use high voltage power sources. This can
overload the unit and cause a fire. Do not use a DC
power source. Check the source carefully when setting
the unit up on a ship or other place where DC is used.
Ensure the AC mains lead is connected correctly and
not damaged. Poor connection and lead damage can
cause fire or electric shock. Do not pull, bend, or place
heavy items on the lead.
Grasp the plug firmly when unplugging the lead. Pulling
the AC mains lead can cause electric shock. Do not
handle the plug with wet hands. This can cause electric
shock.
Do not let metal objects fall inside the unit. This can
cause electric shock or malfunction.
Do not let liquids get into the unit. This can cause
electric shock or malfunction. If this occurs, immediately
disconnect the unit from the power supply and contact
your dealer.
Do not spray insecticides onto or into the unit. They
contain flammable gases which can ignite if sprayed into
the unit.
Do not attempt to repair this unit by yourself. If sound is
interrupted, indicators fail to light, smoke appears, or any
other problem that is not covered in these instructions
occurs, disconnect the AC mains lead and contact your
dealer or an authorized service center. Electric shock or
damage to the unit can occur if the unit is repaired,
disassembled or reconstructed by unqualified persons.
Extend operating life by disconnecting the unit from the
power source if it is not to be used for a long time.
Placement
Voltage
AC mains lead protection
Foreign matter
Service
Specifications/Safety precautions
