Parts identication
a
b
c
A Main body
1 Trimming height indication
mark
2 Dial (Height adjustment
control)
3 Power switch
4 Appliance socket
5 Water inlet
6 Lamp display
a. Battery capacity lamp
b. Switch lock lamp ( )
c.
Charge status lamp ( )
B Blade
7 Cleaning lever
8 Moving blade
9 Stationary blade
: Mounting hook
C Trimming height comb
attachment (1 mm (1/32”)
to 10 mm (13/32”))
D AC adaptor (RE7-87)
(The shape of the power
plug differs depending on
the area�)
; Adaptor
< Power plug
= Cord
> Appliance plug
Accessories
E Cleaning brush
F Oil
G Pouch
Preparation
Charging
• Turn the appliance off.
• Wipe off any water droplets on the appliance socket.
1
Connect the appliance plug to the
appliance socket�
2
Plug in the adaptor into a
household outlet�
• Check that the charge
status
lamp ( )
glows.
• Charging is completed after approx.
1 hour.
To Next Page
