Panasonic EYFLB1A - Specifications

- 23 -
VII . SPECIFICATIONS
MAIN UNIT
Model EYFLB1 EYFLB2 EYFLB3
A A Q A J
Moter 10.8 V DC
Chuck size Single-
ended
9 – 9.5 mm
(23/64" – 3/8")
9 – 9.5 mm
(23/64"
– 3/8")
□
9.5 mm
(3/8")
9 – 9.5 mm
(23/64"
– 3/8")
□
12.7 mm
(1/2")
Double-
ended
12 mm (15/32") 12 mm
(15/32")
12 mm
(15/32")
No load speed 0 – 2300 min
-1
(rpm)
Impact per minute 0 – 4000 min
-1
(ipm) 0 – 3600 min
-1
(ipm) 0 – 3000 min
-1
(ipm)
Maximum torque 40 N·m
(408 kgf-cm, 354 in-lbs)
90 N·m
(918 kgf-cm, 796 in-lbs)
120 N·m
(1224 kgf-cm, 1062 in-lbs)
Overall length 158 mm (6-7/32") 164 mm
(6-7/16")
158 mm
(6-7/32")
164 mm
(6-7/16")
Weight (with battery
pack: EYFB30)
1.3 kg (2.8 lbs) 1.35 kg (2.9 lbs)
BATTERY PACK (not included with shipment)
Model EYFB30 EYFB31
Storage battery Li-ion battery
Battery voltage 10.8 V DC (3.6 V/6 cells) 10.8 V DC (3.6 V/3 cells)
BATTERY CHARGER (not included with shipment)
Model EY0L82
Rating See the rating plate on the bottom of the charger.
Weight 0.93 kg (2.0 lbs)
[Li-ion battery pack]
Model EY0L82
Charging time
EYFB30
Usable: 35 min.
Full: 45 min.
EYFB31
Usable: 30 min.
Full: 35 min.
NOTE: This chart may include models that are not available in your area. Please refer
to the latest general catalog.
Remote control (not included with shipment)
Model EYFA30
Battery voltage 3 V DC
Dimensions 54 mm (2-1/8") × 86 mm (3-3/8") × 10 mm (13/32”)
Weight (with battery) Approximately 29 g (0.6 lbs)
