Panasonic FV-0511VHL1

No.
Part No. Part Name Q´ty Remark
1 FFV51VHL190
Frame Unit 1
2 FFV51VHL191
Adapter Unit 1
3 FFV0511VHL1
Main PCB Unit 1
4 FFV51VHL193
SP Motor Cover 1
5 FFV5VHL1902
Casing Adapter Unit 1
6 FFV51VHL181
Filter Guide 1
7 FFV5VHL1813
Filter 1
8 FFV51VHL170
Heater Unit 1
9 FFV5VHL1810
Grill Assembly 1
A FFVXTT4-8FFJ
Screw (ST4-8) 1
B FFV7000089S
Truss Tap Screw
9
C FFV7000065S
Bind Screw 4
No.
Part No. Part Name Q´ty Remark
10 FFV5VHL1913 Connector Plate
1
11 FFV3450010S Earth Lead Wire
1
12 FFV51VHL130 Connector Assy
1
13 FFV11QCL1341A Connector Assy (L)
1
14 FFV11QCL1912A Junction Cover
1
A FFVXTT4-8FFJ
Screw (ST4-8) 3
D FFVXYM4DC8BN Screw
1
No.
Part No. Part Name Q´ty Remark
15 FFV11QCL1M21AX Motor Assembly
1
16 FFV15VQ10904 Motor Support
1
17 FFVM15VK10802B Blade
1
18 FFV7020021S Nut
1
19 FFV5VHL1906 Casing
1
A FFVXTT4-8FFJ
Screw (ST4-8) 3
B FFV7000089S
Truss Tap Screw
5
Main Body Section
Adapter Unit
Casing Unit
9
4. Parts List
FV-0511VHL1
!
!
!
!
!
!
!
!
!
!
