Panasonic FV-08VKML2 - Installation III ( -Joist Mounting) I

(FV-08VKML2)
(FV-08VKSL2)
Screwdriver
Screw(ST4.2X12)II
2Longscrews
(ST4.2X20)
Screw(ST4.2X12)II
2Longscrews
(ST4.2X20)
4Longscrews(ST4.2X20)
Machinescrew
Plugconnector
Receptacle
Fig.11
Fig.12
Fig.13
Fig.14
I-joist
Suspension
bracket III
INSTALLATION(JOISTMOUNTING-)CONTINUED
INSTALLATION(-JOISTMOUNTING)
6.Securethefanbodytoadaptorbyusingmachine
screwandplugconnectortoreceptacle(Fig.11)
7.Securethesuspensionbrackettojoistsbyusing
longscrews(ST4.2X20)andsecureittofanbodyby
usingscrew(ST4.2X12)inverticaldirection(Fig.12)II
8.Followsteps7to12ofInstallation(page10)to
completetheinstallationwork.
I
C1
C2
C3
C4
Suspensionbracket
Thesuspensionbracketcancomplywith
differentkindof-joists.
III
III
I
1.Beforeinstallation,securethelightingunittofanbody
(referingtoFig.5ofpage10).
2.Connectthesuspensionbrackettofanbody.(Fig.13)
(Selecttheholebychecking-joistsizeandfixthe
screwtotheframehole.)
III
Ⅰ
3.Connectthefanbodytothe-joist.(Fig.14)Ⅰ
4.Followsteps4to12ofinstallation(page9,page10)to
completetheinstallationwork.
I
12
4kindsof-joist
inches(mm)
Ⅰ
9/16(14.3)
C1
C2
C3
C4
11/16(17.5)
31/32(24.6)
117/32(38.9)
hole
mark
