Panasonic FV-08VKML2 - Installation I (Joist Mounting- ) I

INSTALLATION(JOISTMOUNTING-)
IMPORTANT:
Adaptor
Damper
Tape
Joists
2-Screw(ST4.2X8)I
Suspensionbracket II
Suspensionbracket III
SpacingAoncenterjoists
12inches
InsertSuspensionbracket
RefertoFig.1-1
RefertoFig.1-2
RefertoFig.1-3
RefertoFig.1-4
16inches
19.2inchesverticaljoists
24inches
Removethetapefromdamperandadaptor
beforeinstallation.Asshownbelow:
IfspacingAoncenterjoistsis24inches,connect
suspensionbracketand(C4marktoC4mark)
asshownbelow:
IIIII
1.Insertthesuspensionbracketintothefanbodyand
adaptor.(Selectthesuspensionbracketasshownbelow.)
Fanbody
Fanbody
Fanbody
Fanbody
Suspension
bracket I
Suspension
bracket III
Suspension
bracket III
Suspension
bracket III
Suspension
bracket II
Suspension
bracket I
Suspension
bracket I
Suspension
bracket I
Fig.1-1
Fig.1-2
Fig.1-3
Fig.1-4
8
