Panasonic FV-08VKML2 - Installation I (Suspended between Joist Mounting)

INSTALLATION(SUSPENDEDBETWEENJOISTMOUNTING)
1.Beforeinstallation,securethelightingunittofanbody
(referingtoFig.5ofpage10).
2.Insertthesuspensionbracketintobracketcoverof
adaptorsideandthebackofthefanbody.
(Fig.15-1,15-2)
(selectthesuspensionbracketaccordingtospacingA
asshownbelow.)
16inchesand19.2inches
horizontaljoist
Suspensionbracket I
Suspensionbracket I
Suspensionbracket III
Suspensionbracket III
Suspensionbracket II
Suspensionbracket II
16inchesand19.2inches
horizontaljoist
19.2inchesverticaljoist
Fig.15-1
Fig.15-2
Fig.16
Fig.17
Fig.18
Joist
2Longscrews(ST4.2X20)
4Longscrews(ST4.2X20)
2Screw
(ST4.2X12)
II
Joists
Adaptor
Junctionbox
Fanbody
5/8(15.9)
3.Insertthefanbodybetweenjoists.Makesurethefan
bodyislevelandsquare(perpendicular)withthejoists.
(Fig.16)
Ifinstallingwithfanbodyflangebelowdrywall,keep
thedistanceB(1/inch,12.7mmor5/8inch,15.9mm)
forthethicknessofceilingboard.
2
4.Securethesuspensionbrackettojoistsbyusinglong
screws(ST4.2X20)(Fig.17,Fig.18)
5.Securethesuspensionbrackettofanbodybyusing
screw(ST4.2X12)(Fig.18)II
6.Followsteps4to12ofinstallation(page9,page10)
tocompletetheinstallationwork.
I
13
Inches(mm)
131/4153/4(336400)~~
161/2183/4(419480)~~
35(76126)
54/574/5(148198)
~~
~~
1/2(12.7)
