15
Maintenance (Cleaning)
II
Disconnect power source before working on unit. Routine maintenance must be done every year.
1. Never use gasoline, benzene, thinner or any other similar chemicals for cleaning the grille and the
ventilating fan.
2. Do not allow water to enter motor.
3. Do not expose plastic parts to temperature over 140 F (60 C).
Remove grille. (Squeeze mounting spring and pull down)
Wash and clean grille. (Use non-abrasive kitchen
detergent)
Remove dust and dirt from fan body using a vacuum
cleaner. (Remove bulbs if necessary.)
Using a cloth dampened with kitchen detergent,
remove any dirt from fan body. Wipe dry with new
cloth.
Replace bulbs and grille.
WARNING:
CAUTION:
1.
2.
(Fig. 31)
(Fig. 32)
(Fig.33)
(Fig. 27)
4.
Fig. 32
Fig.34
Fig. 33
Vacuum cleaner
Fig. 31
Slot
Mounting spring
Gloves
Grille
3.
5.
(Fig. 34)
To Next Page
