2 Service Navigation
2.1 Introduction
This service manual contains technical information, which allow service personnel’s to understand and service this model
Please place orders using the parts list and not the drawing reference numbers.
2.2 Important Notice
2.2.1 About LENS MAIN UNIT (Ref. 220)
1.
lens adjustments.
2.
209), to maintain Serial number of owner's original lens.
Fig. 1-1
3. No adjustment is required when replacing the part mentioned on Fig.1-1. But, when tighten the concerned screws,apply proper torque
To Next Page
