17
VQT2H52
19 Lens cover
20 Lens cover opening/closing switch
When not using the unit, close the lens cover to
protect the lens.
≥ Slide the opening/closing switch to open/close
the cover.
21 Lens
22 Built-in flash (l 63)
23 Video light (l 52)
24 Recording lamp (l 31)
25 Recording start/stop button (l 42)
26 SD card open lever [OPEN] (l 25)
27 Status indicator (l 26)
28 Photoshot button [ ] (l 46)
29 Zoom lever [W/T] (In recording mode)
(l 49)
Thumbnail display switch/Volume lever
[s /VOLr] (In playback mode) (l 71)
30 Speaker
31 Internal stereo microphones
32 Card slot (l 25)
33 SD card cover (l 25)
34 Access lamp [ACCESS] (l 15, 25)
20
19
22
21
23
24
26
25
30
2928
27
31
35
32
33
34
