Note:
¡For additional equipment protection, we recommend the use of a surge protector. The following types are
available; TELESPIKE BLOK MODEL TSB (TRIPPE MFG. CO.), SPIKE BLOK MODEL SK6-0 (TRIPPE
MFG. CO.), SUPER MAX (PANAMAX) or MP1 (ITW LINX).
¡When you operate this product, the power outlet should be near the product and easily accessible.
Connections
Dialing mode switch:
Set to TONE.
¡If you cannot dial,
set to PULSE.
Power outlet
(120 V, 60 Hz)
Single telephone line
(RJ11C)
Power cord
Telephone line cord
TONE
DIALING MODE
PULSE
Helpful hint:
¡If assistance is needed, press (HELP). The unit will print a quick reference.
Power surge
protector
Line surge
protector
(
)
( )
(HELP)
