1. Introduction and Installation
11
For Fax Advantage assistance, call 1-800-435-7329.
6 Make sure that the triangles (1) match, to
install the toner cartridge correctly.
7 Lift open the front cover (1), holding OPEN
(2).
8 Install the drum and toner unit (1) by holding
the tabs.
L Do not touch the transfer roller (2).
L If the lower glass (3) is dirty, clean it with
a soft and dry cloth.
9 Close the front cover (1) by pushing down
on both sides, until locked.
L While the unit displays “PLEASE WAIT”,
do not open the front cover, or disconnect
the power cord.
Toner save feature
If you want to reduce toner consumption, set the
toner save setting to ON (feature #79 on page
49). The toner cartridge will last approximately
40% longer. This feature may lower the print
quality.
1
1
2
1
2
3
1
FL511.book Page 11 Thursday, April 17, 2003 1:42 PM
