Operating Instructions
[For assistance, please call: 1-800-272-7033] 77
Specifying Pan/Tilt Range
1. Access the camera (see page 13), and click [Single] at the top of the Top page.
2. Open another web browser, and display the Camera page (see page 73).
3. Align the Single Camera page and the Camera page side to side.
4. Set the pan/tilt range.
• Selecting [Current Settings] displays the current angle of the camera.
Select each value while adjusting the pan/tilt on the Single Camera page.
Note
The values must be selected as minimum home position maximum.
5. Click [Save] on the Camera page.
• New settings are saved. The camera turns to the home position.
Max.: +20 ˚
Max.: +60 ˚
Min.: -60 ˚
Min.: -45 ˚
To Next Page
