Connection
Wall Mounting
1
Pull down the handset hook until it locks,
so the tab holds the handset.
2
Remove the attached stand.
3
Mount the unit on the wall.
To temporarily place the handset down
during a conversation, hook it over the
top edge of the phone as shown.
CAUTION
Ensure the cords are inserted
in the groove to prevent
damage to the connector.
Connect to a KX-TDA series
Business Telephone System
.
The telephone line cord
(included)
< Back view>
The availability of D-XDP function depends on the software version of the connected
Business Telephone System. Consult your dealer for more details about D-XDP.
•
Connect to a digital proprietary telephone
for D-XDP
().
TO MAIN UNIT
/PABX
()
TO DIGITAL
2
1
—
8
—
