Panasonic KX-TH1211B - Fixtures and Tools

143
KX-TH1211B/KX-TH1212B/KX-TGA930T
16.5.4.3. KX-TGA930T
16.5.5. Screws
16.5.6. Fixtures and Tools
Note:
(*1) When replacing the Handset LCD, see How to
Replace the Handset LCD (P.91).
(*2) When downloading the Flash Program, see
Downloading the Flash Program (P.78).
(*3) When setting Test Mode using U-ART Jig, see Test
Mode (P.51) and Measurements and Adjustments (P.93).
H.R./N
KXTH1211B
KXTH1212B
KXTGA930T
Safety Ref.
No.
Part No. Part Name & Description Remarks
A201 PQLV209T AC ADAPTOR (for Charger
Unit)
A202 PNQX1006Z INSTRUCTION BOOK (*1)
A203 PQQW15385Z LEAFLET, #800
A204 PNKE1004Z1 HANGER, BELT CLIP ABS-HB
P201 XZB08X25B02 PROTECTION COVER (for
Handset)
P202 PNPM1003Z PROTECTION COVER (for
Charger Unit)
P203 PNPK1035Z GIFT BOX
P204 PQXDDS400-8 MAGNET ELECTRIC
TRANSDUCER, SECURITY TAG
Safety Ref.
No.
Part No. Part Name & Description Remarks
A XTB26+8GFJ TAPPING SCREW
B XTB2+8GFJ TAPPING SCREW
Safety Ref.
No.
Part No. Part Name & Description Remarks
PQZZ430PIR TIP OF SOLDERING IRON
(*1)
PQZZ430PRB RUBBER OF SOLDERING IRON
(*1)
PQJA10166Z CORD, USB (*2)
PNZZTH1211M BATCH FILE CD-ROM (*2)
PNUPUARTJIG2 PCB (for U-ART Jig) (*3)
