17 Monitor (P50)
18
[ ] (Post Focus) button (P36)/[Fn2]
button (P30)
19
[LVF] button (P23)
20
Viewfinder (P23, 50)
21
Dioptre adjustment dial
• Adjust until you can see the characters
displayed in the viewfinder clearly.
22
Zoom button (P24)
23
[(] (Playback) button (P41)
24
[DISP.] button
• Each time this is pressed, the display
on the monitor is switched.
25
Cursor buttons (P26)
26 [MENU/SET] button (P26)
27
Charging lamp (P21)/
Wi-Fi
®
connection lamp (P44)
28
[ ] (Delete) button (P41)/[ ]
(Cancel) button/[Q.MENU] button
29
[ ] (4K Photo Mode) button (P33)/
[Fn1] button (P30)
30
[MODE] button (P27)
31
Drainage hole
32
Tripod mount
• It may not be possible to attach and
securely fasten a tripod with a screw
length of 5.5 mm (0.22 inch) or more
to the camera. Doing so may also
damage the camera.
