Panasonic Lumix DC-GH5 Basic Operating Instructions

Preparation/Basic “Quick Start Guide”
12
DVQX1072 (ENG)
Card access indicators
• During access (i.e., while the access lamp is lit up or [ ]/[ ] is displayed), do not turn
this unit off, remove the battery, card or disconnect the AC adaptor (optional).
Furthermore, do not subject the camera to vibration, impact or static electricity.
The card or the data on the card may be damaged, and this unit may no longer operate
normally.
If operation fails due to vibration, impact or static electricity, perform the operation
again.
• With [Double Slot Function] in the [Setup] menu, you can set the way recording to the two card
slots is performed. (P82)
• Change lenses where there is not a lot of dirt or dust.
• Do not press the lens release button A when you attach a lens.
∫ Detaching the lens
1 Attach the lens cap.
2 While pressing on the lens release button B, rotate the
lens toward the arrow until it stops and then remove.
Access lamp
Lights up while the card is
being accessed (during
recording, deletion,
formatting, etc.).
Access indication
Lights up red while an
image is being recorded to
the card.
5
Attaching/Removing the Lens
DC-GH5BodyGN-DVQX1072_eng.book 12 ページ ２０１７年２月１３日 月曜日 午前１１時４５分

Panasonic Lumix DC-GH5 Specifications

General

Camera Type	Mirrorless
Sensor Type	Live MOS
Effective Pixels	20.3 MP
Image Processor	Venus Engine
Lens Mount	Micro Four Thirds
Video Format	MOV, MP4
Battery Life	Approx. 410 shots (CIPA standard)
Dimensions	138.5 x 98.1 x 87.4 mm
Sensor Size	17.3 x 13 mm
ISO Range	200-25600
Shutter Speed	1/16000 to 60 sec
Continuous Shooting	12 fps
Video Recording	4K up to 60p
Internal Recording	4:2:2 10-bit
Viewfinder	OLED Live View Finder, 3, 680k dots
Screen	3.2"
Autofocus System	Contrast Detect DFD
Image Stabilization	5-axis sensor-shift
Memory Card Slots	Dual SD/SDHC/SDXC (UHS-II compatible)
Connectivity	Wi-Fi, Bluetooth, HDMI, USB 3.1
Battery	DMW-BLF19 (Lithium-ion)
Weight	Approx. 725 g (with battery and memory card)
