Panasonic Lumix DC-GH5 Basic Operating Instructions

13
Preparation/Basic “Quick Start Guide”
(ENG) DVQX1072
At the time when this camera is purchased, the monitor is stowed in the camera body.
Bring out the monitor as shown below.
1 Open the monitor. (Maximum 180o)
2 It can be rotated 180o forward.
3 Return the monitor to its original position.
• When rotating the monitor, be careful not to apply too much force. Doing so may cause
damage.
• When not using the monitor it is recommended that you close it with the screen facing inward to
prevent dirt and scratches.
• The clock is not set when the camera is shipped.
1 Turn the camera on.
• When the camera is turned on, the status indicator 1
lights up.
2 Press [MENU/SET].
3 Press 2/1 to select the items (year, month, day,
hour, minute), and press 3/4 to set.
4 Press [MENU/SET] to set.
5 When [The clock setting has been completed.] is
displayed, press [MENU/SET].
6 When [Please set the home area] is displayed, press
[MENU/SET].
7 Press 2/1 to select the home area, and then press
[MENU/SET].
6
Opening the Monitor
7
Setting Date/Time (Clock Set)
DC-GH5BodyGN-DVQX1072_eng.book 13 ページ ２０１７年２月１３日 月曜日 午前１１時４５分

Panasonic Lumix DC-GH5 Specifications

General

Camera Type	Mirrorless
Sensor Type	Live MOS
Effective Pixels	20.3 MP
Image Processor	Venus Engine
Lens Mount	Micro Four Thirds
Video Format	MOV, MP4
Battery Life	Approx. 410 shots (CIPA standard)
Dimensions	138.5 x 98.1 x 87.4 mm
Sensor Size	17.3 x 13 mm
ISO Range	200-25600
Shutter Speed	1/16000 to 60 sec
Continuous Shooting	12 fps
Video Recording	4K up to 60p
Internal Recording	4:2:2 10-bit
Viewfinder	OLED Live View Finder, 3, 680k dots
Screen	3.2"
Autofocus System	Contrast Detect DFD
Image Stabilization	5-axis sensor-shift
Memory Card Slots	Dual SD/SDHC/SDXC (UHS-II compatible)
Connectivity	Wi-Fi, Bluetooth, HDMI, USB 3.1
Battery	DMW-BLF19 (Lithium-ion)
Weight	Approx. 725 g (with battery and memory card)
