Recording
68
DVQX1072 (ENG)
Using a stereo shotgun microphone (DMW-MS2: optional) or stereo microphone
(VW-VMS10: optional), you can record sounds with quality superior to those recorded with
the built-in microphone.
Using the stereo shotgun microphone (DMW-MS2: optional), you can switch between the
gun (ultra-directional) recording and the wide range stereo recording.
Preparations:
• Turn this unit off.
• When attaching the stereo shotgun microphone to the camera, remove the hot shoe cover.
(P53)
∫ Setting the range within which the stereo shotgun microphone (DMW-MS2:
optional) will record sounds
1 Attach the dedicated stereo shotgun microphone to this unit, and then turn this
unit on.
2 Select the menu. (P24)
• This item is available only when using a stereo shotgun microphone.
3 (When [MANUAL] is selected)
Press 2/1 to select a range, and press [MENU/SET].
• When the external microphone is connected, [Mic Level Disp.] is automatically set to [ON], and
the mic level is displayed on the screen.
• When a stereo microphone (VW-VMS10: optional) is used, [Special Mic.] is fixed to [STEREO].
• When [Special Mic.] is set to [LENS AUTO], [S.SHOTGUN] or [MANUAL], [Sound Output] in
the [Motion Picture] menu is fixed to [REC SOUND].
• For details, refer to the operating instructions of the external microphone.
External Microphone (optional)
A Hot shoe
B [MIC] socket
C Stereo shotgun microphone (DMW-MS2: optional)
Stereo microphone (VW-VMS10: optional)
> [Motion Picture] > [Special Mic.]
[STEREO]
Allows stereo recording of sound over a wide area.
[LENS AUTO]
Allows recording within the range that is set automatically according
to the angle of view of the lens.
[SHOTGUN]
Allows recording from one direction by shutting out background and
surrounding noise.
[S.SHOTGUN]
Allows recording within the range even narrower than that of
[SHOTGUN].
[MANUAL]
Allows recording within the range you set manually.
DC-GH5BodyGN-DVQX1072_eng.book 68 ページ ２０１７年２月１３日 月曜日 午前１１時４５分
