69
Recording
(ENG) DVQX1072
By attaching an XLR microphone adaptor (DMW-XLR1: optional) to the camera, you can
use a commercially-available XLR microphone to enable the recording of superior-quality
high-res/stereo sound.
Preparations:
Turn this unit off.
Remove the hot shoe cover that is attached to the camera. (P53)
Setting the sampling frequency
1 Attach the XLR microphone adaptor to the hot shoe of this unit, and then turn
this unit on.
2 Select the menu. (P24)
This item is available only when using an XLR microphone adaptor.
The set sampling frequency is also applied to the sound output via HDMI. With [Sound
Down Convert] in [HDMI Rec Output], you can down-convert the sound output via HDMI.
(P67)
For details, refer to the operating instructions of the XLR microphone adaptor.
You can record motion pictures while hearing the sounds that are being recorded by
connecting a commercially available headphones to this unit.
Adjusting the headphone volume
Connect headphones, and rotate the control dial while the recording screen is
displayed or a motion picture is being played back.
You can also adjust the volume by touching [ ] or [ ] during playback.
XLR Microphone Adaptor (optional)
A Hot shoe B XLR microphone adaptor (DMW-XLR1: optional)
C Commercially available XLR microphone
> [Motion Picture] > [XLR Mic Adaptor Setting]
[96kHz/24bit]
Records high-res sound at
96 kHz/24bit.
Only available when [Rec
Format] is set to [MOV].
[48kHz/24bit]
Records high-quality sound at
48 kHz/24bit.
[48kHz/16bit] Records standard-quality sound at 48 kHz/16bit.
[OFF] Records sound using the built-in microphone.
Headphone
: Reduce volume level : Increase volume level
MENU
