2. Getting Started/Basic Operations
28
Inserting/Removing the Card (Optional)
• Check that the access lamp has gone off.
1
Slide the card door to open it.
2
Push it securely all the way until you hear a
“click” while being careful about the
direction in which you insert it.
To remove the card, push the card until it
clicks, then pull the card out upright.
• One card can be inserted into each of the card slot 1
A and the card slot 2 B.
• To insert/remove the card into/from the card slot 1
A,
push the top side of the card. To insert/remove the
card into/from the card slot 2
B, push the bottom side
of the card.
C: Do not touch the connection terminals of the card.
3
1: Close the card door.
2: Slide the card door to the end and then
close it firmly.
