43
Basics
Holding the camera
Extending/retracting the lens [when the interchangeable lens
(H-FS12032/H-FS35100) is attached]
â–
How to Extend the Lens
Rotate the zoom ring in the direction of arrow
from position
( ) (the lens is retracted) to position ( ) [12 mm to 32 mm
(H-FS12032), 35 mm to 100 mm (H-FS35100)] to extend the
lens.
• When the lens barrel is retracted, images cannot be
recorded.
The lens is retracted
Example: H-FS12032
â–
How to Retract the Lens
Rotate the zoom ring in the direction of arrow
from position
( ) [12 mm to 32 mm (H-FS12032), 35 mm to 100 mm
(H-FS35100)] to position ( ) to retract the lens.
• The zoom ring will seem to click into the 12 mm position
(H-FS12032) or 35 mm position (H-FS35100), but continue
to rotate the lens until it reaches position ( ).
• When you are not recording images, we recommend that
you retract the lens.
The lens is extended
To Next Page
