12
Preparations
DVQX1237 (ENG)
1 Shutter button (→18)
2
Zoom lever (→19)
3
Motion picture button (→35)
4
Camera [ON/OFF] button (→16)
5
Mode dial (→20)
6
Stereo microphone (→17)
7
Viewfinder (→17, 51)
8
Diopter adjustment dial
• Rotate the diopter adjustment dial
to adjust until you are able to clearly
see the characters displayed in the
viewfinder.
9
Eye sensor (→17)
10
Strap eyelet
• To prevent dropping, be sure to
attach the supplied strap and fit it to
your wrist.
11
Speaker (→17)
12
Control ring (→22)
13
Lens barrel
14
Lens
15
Self-timer indicator /
AF Assist Lamp (→17)
16
Flash (→17)
17
[LVF] button (→17) / [Fn4] button (→23)
18
Charging lamp (→15) /
Wi-Fi
®
connection lamp
19
[ ] ([Post Focus]) button (→32) /
[Fn2] button (→23)
20
Control dial (→22)
21
[Q.MENU/
] (Cancel) button /
[
] (Delete) button (→39) /
[Fn3] button (→23)
• You can easily call some of the menu
items and set them during recording.
22
[
] (4K photo mode) button (→29) /
[Fn1] button (→23)
23
[ ] (Playback) button (→39)
24
Cursor button (→21)
25
[MENU/SET] button
• Confirmation of setting contents, etc.,
is performed.
26
[DISP.] button
• Use this to change display.
27
[HDMI] socket
• You can view pictures on a TV screen
by connecting your camera to your TV
with the HDMI micro cable.
28
[USB/CHARGE] socket (→14)
29
Card/Battery door (→13)
30
Release lever (→13)
31
DC coupler cover (→60)
32
Tripod mount
• Do not attach this unit to tripods that
have screws with a length of 5.5 mm
(0.22 inch) or more. Doing so may
damage this unit or the unit may not be
secured properly on the tripod.
33
Touch screen (→23) / monitor (→17, 51)
●
Always use a genuine Panasonic
AC adaptor (DMW-AC10E: optional).
(→60)
When using an AC adaptor (DMW-
AC10E: optional), ensure that the
Panasonic DC coupler (DMW-
DCC11: optional) and AC adaptor
(DMW-AC10E: optional) are used.
●
[Fn5] to [Fn9] (→23) are touch icons.
They are displayed by touching the
[
] tab on the recording screen.
