16
Preparations/Basics
DVQX2305 (ENG)
1 Shutter button (→23)
2
Zoom lever (→24)
3
Motion picture button (→39)
4
Camera [ON/OFF] button (→20)
5
Mode dial (→22)
6
Stereo microphone
7
Viewfinder (→21)
8
Diopter adjustment dial
• Rotate the diopter adjustment dial
to adjust until you are able to clearly
see the characters displayed in the
viewfinder.
9
Eye sensor (→21)
10
Strap eyelet
• To prevent dropping, be sure to
attach the supplied strap and fit it to
your wrist.
11
Speaker
12
Control ring (→25)
13
Lens barrel
14
Lens
15
Self-timer indicator / AF Assist Lamp
16
Flash
17
[LVF] button (→21) / [Fn4] button (→27)
18
Charging lamp (→18, 19) /
WIRELESS connection lamp (→50)
19
[
] ([Zoom Compose Assist]) button
(→25) / [Fn2] button (→27)
20
Control dial (→25)
21
[
] (Delete) button (→41) /
[Q.MENU] button /
• You can easily call some of the menu
items and set them during recording.
[
] (Cancel) button (→28) /
[Fn3] button (→27)
22
[
] ([Post Focus]) button (→36) /
[Fn1] button (→27)
23
[
] (Playback) button (→41)
24
Cursor button (→26)
25
[MENU/SET] button (→28)
• Confirmation of setting contents, etc.,
is performed.
26
[DISP.] button
• Use this to change display.
27
[HDMI] socket
• You can view pictures on a TV screen
by connecting your camera to your TV
with the HDMI micro cable.
28
[USB/CHARGE] socket (→18)
29
Card/Battery door (→17)
30
Release lever (→17)
31
DC coupler cover (→14)
32
Tripod mount
• Do not attach this unit to tripods that
have screws with a length of 5.5 mm
(0.22 inch) or more. Doing so may
damage this unit or the unit may not be
secured properly on the tripod.
33
Touch screen (→27) / monitor (→59)
●
Always use a genuine Panasonic AC
adaptor (DMW-AC10PP: optional).
(→14)
When using an AC adaptor, ensure
that the Panasonic DC coupler
(DMW-DCC11: optional) and AC
adaptor (DMW-AC10PP: optional)
are used.
Function buttons [Fn5] to [Fn9] are
touch icons.
They can be displayed by touching the
[
] tab on the recording screen.
To Next Page
