Before Use
- 8 -
11 Camera ON/OFF switch (P18)
12 Zoom lever (P38)
13 Speaker (P95)
14 Microphone (P70)
15 Shutter button (P31, 70)
16 Intelligent auto button (P31)
17 Hand strap eyelet
• Be sure to attach the hand strap when
using the camera to ensure that you will
not drop it.
18 Lens barrel
19 [AV OUT/DIGITAL] socket (P108, 111,
117)
20 Tripod receptacle
• When you use a tripod, make sure the
tripod is stable when the camera is
attached to it.
21 Card/Battery door (P14, 15)
22 Release lever (P14)
23 DC coupler cover (P15)
• When using an AC adaptor, ensure that
the Panasonic DC coupler (optional) and
AC adaptor (optional) are used. For
connection details, refer to P15.
