- 13 -
Before Use
19 Cursor buttons
A: 3/Exposure compensation (P63)
Auto Bracket (P64)
B: 4/Macro Mode (P61)
AF Tracking (P87)
C: 2/Self-timer (P62)
D: 1/Flash setting (P57)
20 Speaker (P47)
•
Be careful not to cover the speaker with your finger.
Doing so may make sound difficult to hear.
21 Tripod receptacle
22 [AV OUT/DIGITAL] socket (P114, 117, 120, 123)
23 Card slot (P19)
24 Battery slot (P19)
In these operating instructions, the cursor buttons are described as shown in the
figure below or described with 3/4/2/1.
e.g.: When you press the 4 (down) button
or Press 4
20 21
モヷチヰヶヵチバチュリヨリヵ モロ
23
22
24
