VQT1T03 (ENG)
8
Names of the Components
1Flash
2 Lens
3 Self-timer indicator
AF assist lamp
4 LCD monitor
5 Status indicator
6 [MENU/SET] button
7 [DISPLAY] button
8 [Q.MENU]/Delete button
9 [REC]/[PLAYBACK] selector switch
10 Cursor buttons
A: 3/Exposure compensation/Flash
output adjustment/Auto bracket/
Colour bracket
B: 4/Macro mode
AF Tracking
C: 2/Self-timer button
D: 1/Flash setting button/White balance
fine adjustment
In these operating instructions, the cursor buttons are described as shown in the
figure below or described with 3/4/2/1.
e.g.: When you press the 4 (down) button
or Press 4
DMC-FX180GC-VQT1T03_mst.book 8 ページ ２００８年７月１４日 月曜日 午後３時１３分
