- 11 -
Before Use
Names of the Components
1Flash (P51)
2 Lens (P5, 140)
3 Self-timer indicator (P57)
AF assist lamp (P94)
4 LCD monitor (P49, 136)
5 Status indicator (P18, 29, 35)
6 [MENU/SET] button (P21)
7 [DISPLAY] button (P49)
8 [Q.MENU] (P26)/Delete (P47) button
9 [REC]/[PLAYBACK] selector switch
(P23)
10 Cursor buttons
A: 3/Exposure compensation (P58)/
Auto bracket (P59)/White balance
fine adjustment (P86)
B: 4/Macro mode (P56)
AF Tracking (P37, 89)
C: 2/Self-timer button (P57)
D: 1/Flash setting button (P51)
In these operating instructions, the cursor buttons are described as shown in the
figure below or described with 3/4/2/1.
e.g.: When you press the 4 (down) button
or Press 4
12 3
