Panasonic Lumix DMC-FX700 Basic Operating Instructions

VQT2X96 (ENG)
4
∫ Cautions for Use
• Do not use any other AV cables except the supplied one.
• Always use a genuine Panasonic HDMI mini cable (RP-CDHM15, RP-CDHM30;
optional).
Part numbers: RP-CDHM15 (1.5 m), RP-CDHM30 (3.0 m)
• Do not use any other USB connection cables except the supplied one.
Keep this unit as far away as possible from electromagnetic equipment
(such as microwave ovens, TVs, video games etc.).
• If you use this unit on top of or near a TV, the pictures and/or sound on this unit
may be disrupted by electromagnetic wave radiation.
• Do not use this unit near cell phones because doing so may result in noise
adversely affecting the pictures and/or sound.
• Recorded data may be damaged, or pictures may be distorted, by strong
magnetic fields created by speakers or large motors.
• Electromagnetic wave radiation generated by microprocessors may adversely
affect this unit, disturbing the pictures and/or sound.
• If this unit is adversely affected by electromagnetic equipment and stops
functioning properly, turn this unit off and remove the battery or disconnect AC
adaptor (DMW-AC5G; optional). Then reinsert the battery or reconnect AC
adaptor and turn this unit on.
Do not use this unit near radio transmitters or high-voltage lines.
• If you record near radio transmitters or high-voltage lines, the recorded pictures
and/or sound may be adversely affected.
The optional HDMI mini cable is available only for DMC-FX700GC/DMC-FX700GH.
The optional AC adaptor is available only for DMC-FX700GC/DMC-FX700GH.
∫ How to replace the Fuse
The location of the fuse differ according to the type of AC cable (figures A and B).
Confirm the AC cable fitted and follow the instructions below.
Illustrations may differ from actual AC cable.
1 Open the fuse cover
with a screwdriver.
2 Replace the fuse and
close or attach the fuse
cover.
Fuse cover
Figure A Figure B
Figure A Figure B
Fuse
(5 ampere)
Fuse
(5 ampere)
DMC-FX700GCGHSG-VQT2X96_eng.book 4 ページ ２０１０年７月２０日 火曜日 午前１１時２７分

Panasonic Lumix DMC-FX700 Specifications

General

Megapixel	14.1 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	Yes
Image sensor size	1/2.33 \
Image formats supported	JPG
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	4320 x 3240 pixels
Still image resolution(s)	4320 x 3240
Optical zoom	5 x
Focal length range	4.3 - 21.5 mm
Minimum aperture number	-
Lens structure (elements/groups)	7/6
Maximum focal length (35mm film equiv)	120 mm
Minimum focal length (35mm film equiv)	24 mm
Interface	AV out, USB 2.0
Power source type	Battery
Normal focusing range	0.5 - ∞ (W), 1 - ∞ (T) m
Auto focusing (AF) modes	Continuous Auto Focus
Normal focusing range (wide)	0.5 - ∞ m
Auto Mode focusing range (tele)	1 - ∞ m
Auto Mode focusing range (wide)	0.03 - ∞ m
Flash modes	auto, Red-eye reduction, Slow synchronization
Flash range (tele)	1 - 2.8 m
Flash range (wide)	0.6 - 7.4 m
Internal memory	40 MB
Compatible memory cards	SD, SDHC, SDXC
Maximum video resolution	1280 x 720 pixels
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	230000 pixels
USB version	2.0
Scene modes	Beach, Candlelight, Portrait, Self-portrait, Snow, Landscape (scenery)
Photo effects	Black&White, Sepia
White balance	Auto, Cloudy, Daylight, Shade
Camera playback	Slide show
Self-timer delay	- s
Product color	Black
Battery capacity	940 mAh
Battery life (CIPA standard)	300 shots
Bundled software	PHOTOfunSTUDIO 5.2 HD Edition, QuickTime, Adobe Reader
ISO sensitivity (max)	1600
ISO sensitivity (min)	100
Fastest camera shutter speed	1/2000 s
Slowest camera shutter speed	60 s

Weight and Dimensions

Depth	24.5 mm
Width	103.5 mm
Height	55.8 mm
Weight	155 g
