Panasonic Lumix DMC-G3 User Manual

- 169 -
Connecting to other equipment
Turn on the TV and select the input to match the connecter in use.
Turn the camera on and then press [(].
• Input of the TV will switch automatically and playback screen is displayed when connected to a
VIERA Link compatible TV using an HDMI mini cable with the [VIERA Link] (P67) set to [ON].
(P170)
Note
•
Do not use any other AV cables except the supplied one when connecting with an AV cable.
• Always use a genuine Panasonic HDMI mini cable (RP-CDHM15, RP-CDHM30; optional)
when connecting with an HDMI mini cable.
Part numbers: RP-CDHM15 (1.5 m) (5 feet), RP-CDHM30 (3.0 m) (10 feet)
• Audio will be played back in monaural when connecting with an AV cable.
• Audio will be played back as stereo (2ch) when connecting with an HDMI mini cable.
• Depending on the [ASPECT RATIO], black bands may be displayed on the top and bottom or
the left and right of the pictures.
• Change the screen mode on your TV if the picture is displayed with the top or bottom cut off.
• Output from the HDMI mini cable has priority when both AV cable and HDMI mini cable are
connected.
• The connection with the USB connection cable will take priority when you connect the USB
connection cable simultaneously with the HDMI mini cable.
• When you play back a picture vertically, it may be blurry.
• Proper playback will be dependent on the TV used for viewing.
• The viewfinder cannot be displayed when connected with a AV cable.
• During HDMI output, no picture is displayed on the LCD monitor or viewfinder.
• Read the operating instructions for the TV.
The recorded still pictures can be played back on a TV with an SD Memory Card slot.
•
Proper playback (aspect ratio) will be dependent on the TV used for viewing.
• Motion pictures recorded with [AVCHD] can be played back on Panasonic TVs (VIERA) with
the AVCHD logo mark. In all other cases, connect the camera to the TV using the AV cable
(supplied) and play back the motion picture.
• For cards compatible with playback, refer to the operating instructions of the TV.

Panasonic Lumix DMC-G3 Specifications

General

Camera type	MILC
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	16.6 MP
Image sensor size	- \
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	4592 x 3448 pixels
Image sensor size (W x H)	17.3 x 13 mm
Still image resolution(s)	1712 x 1712, 1824 x 1024, 1824 x 1216, 1824 x 1368, 1920 x 1080, 2272 x 1520, 2272 x 1704, 2416 x 2416, 3232 x 1824, 3232 x 2160, 3232 x 2424, 3424 x 3424, 4576 x 2576, 4576 x 3056, 4592 x 3448
Filter size	52 mm
Digital zoom	4 x
Optical zoom	- x
Focal length range	14 - 42 mm
Number of diaphragm blades	7
Lens structure (elements/groups)	12/9
Aperture range (F-F)	3.5 - 5.6
Camera shutter speed	1/4000 ~ 60 s
Focal length (35mm film equivalent)	28 - 84 mm
Focus	TTL
Auto focusing (AF) modes	Continuous Auto Focus, Multi Point Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Spot
ISO sensitivity	160, 200, 400, 800, 1600, 3200, 6400, Auto
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Scene modes	Children, Cuisine, Museum, Night landscape, Night portrait, Party (indoor), Portrait, Sports, Sunset, Landscape (scenery)
Image editing	Crop, Resizing, Rotating
Photo effects	Neutral, Sepia, Vivid
White balance	Auto, Cloudy, Daylight, Flash, Incandescent, Shade
Camera playback	Slide show, Thumbnails
Self-timer delay	2, 10 s
Camera file system	DCF 2.0, Exif 2.3
Playback zoom (max)	16 x
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN
Video resolutions	320 x 240, 640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	AVCHD, M-JPEG
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
Magnification	1.4 x
USB version	2.0
Product color	Red
Battery voltage	7.2 V
Battery capacity	1010 mAh
Battery life (CIPA standard)	270 shots
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Cables included	AV, USB
Bundled software	PHOTOfunSTUDIO 6.2 HD Edition / SILKYPIX Developer Studio 3.1 SE / Super LoiloScope (trial version) / USB Driver

Weight and Dimensions

Depth	46.7 mm
Width	115.2 mm
Height	83 mm
Weight	366 g
Weight (including battery)	544 g
