Panasonic Lumix DMC-G3 User Manual

Connecting to other equipment
- 170 -
1 Connect this unit to a Panasonic TV compatible with VIERA Link with a HDMI
mini cable (optional) (P168).
2 Turn the camera on and then press [(].
3 Operate with the remote control for the TV.
•
Operate with reference to the operation icons displayed on the screen.
Panasonic TV compatible with VIERA Link
Note
•
To playback the audio of the motion pictures, set the [SOUND] in the Slide Show setting screen
to [AUTO] or [AUDIO].
• Operation icons are hidden, if no operation is performed for a while when the operation icons
are displayed. Operation icons are displayed when one of the following buttons is pressed
while the operation icons are not displayed.
–3/4/2/1, [OK], [SUB MENU], [RETURN], Red button, Green button, Yellow button
• It is recommended to connect this unit to an HDMI terminal other than the HDMI1 if there are 2
or more HDMI input terminals on the TV.
• When the [VIERA Link] (P67) of this unit is set to [ON], operation using the button on this unit
will be limited.
• VIERA Link must be activated on the connected TV. (Read the operating instructions of the TV
for how to set etc.)
• If you are not using VIERA Link, set [VIERA Link] (P67) to [OFF].
Playback using VIERA Link (HDMI) (HDAVI Control™)
What is the VIERA Link?
•
VIERA Link™ is a new name for EZ Sync™.
• This function allows you to use your remote control for the Panasonic TV for easy
operations when this unit has been connected to a VIERA Link compatible device using a
HDMI mini cable (optional) for automatic linked operations. (Not all operations are possible.)
• VIERA Link is a unique Panasonic function built on a HDMI control function using the
standard HDMI CEC (Consumer Electronics Control) specification. Linked operations with
HDMI CEC compatible devices made by other companies are not guaranteed. When using
devices made by other companies that are compatible with VIERA Link, refer to the
operating instructions for the respective devices.
• This unit is compatible with VIERA Link Ver.5. VIERA Link Ver.5 is the newest Panasonic
version and is also compatible with existing Panasonic VIERA Link devices. (As of
December 2010)
Preparations: Set the [VIERA Link] to [ON]. (P67)
1 [SUB MENU]
2 [OK]
3 [RETURN]
¢ The shape of the remote control varies
depending on the region. Operate following
the TV instructions displayed on screen.

Panasonic Lumix DMC-G3 Specifications

General

Camera type	MILC
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	16.6 MP
Image sensor size	- \
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	4592 x 3448 pixels
Image sensor size (W x H)	17.3 x 13 mm
Still image resolution(s)	1712 x 1712, 1824 x 1024, 1824 x 1216, 1824 x 1368, 1920 x 1080, 2272 x 1520, 2272 x 1704, 2416 x 2416, 3232 x 1824, 3232 x 2160, 3232 x 2424, 3424 x 3424, 4576 x 2576, 4576 x 3056, 4592 x 3448
Filter size	52 mm
Digital zoom	4 x
Optical zoom	- x
Focal length range	14 - 42 mm
Number of diaphragm blades	7
Lens structure (elements/groups)	12/9
Aperture range (F-F)	3.5 - 5.6
Camera shutter speed	1/4000 ~ 60 s
Focal length (35mm film equivalent)	28 - 84 mm
Focus	TTL
Auto focusing (AF) modes	Continuous Auto Focus, Multi Point Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Spot
ISO sensitivity	160, 200, 400, 800, 1600, 3200, 6400, Auto
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Scene modes	Children, Cuisine, Museum, Night landscape, Night portrait, Party (indoor), Portrait, Sports, Sunset, Landscape (scenery)
Image editing	Crop, Resizing, Rotating
Photo effects	Neutral, Sepia, Vivid
White balance	Auto, Cloudy, Daylight, Flash, Incandescent, Shade
Camera playback	Slide show, Thumbnails
Self-timer delay	2, 10 s
Camera file system	DCF 2.0, Exif 2.3
Playback zoom (max)	16 x
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN
Video resolutions	320 x 240, 640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	AVCHD, M-JPEG
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
Magnification	1.4 x
USB version	2.0
Product color	Red
Battery voltage	7.2 V
Battery capacity	1010 mAh
Battery life (CIPA standard)	270 shots
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Cables included	AV, USB
Bundled software	PHOTOfunSTUDIO 6.2 HD Edition / SILKYPIX Developer Studio 3.1 SE / Super LoiloScope (trial version) / USB Driver

Weight and Dimensions

Depth	46.7 mm
Width	115.2 mm
Height	83 mm
Weight	366 g
Weight (including battery)	544 g
