Panasonic LUMIX DMC-G7 Basic Operating Instructions

Recording
34
SQT0919 (ENG)
• When the ambient temperature is high or motion picture is recorded continuously, the camera
may display [ ] and stop the recording to protect itself. Wait until the camera cools down.
• It is recommended to use a fully charged battery or AC adaptor (DMW-AC10G: optional) when
recording motion pictures.
• If while recording motion pictures using the AC adaptor (DMW-AC10G: optional) the power
supply is cut off due to a power cut or if the AC adaptor (DMW-AC10G: optional) is
disconnected etc., the motion picture will not be recorded.
• These times are for an ambient temperature of 23 oC and a humidity of 50%RH.
Please be aware that these times are approximate.
• Actual recordable time is the time available for recording when repeating actions such as
turning this unit on and off, starting/stopping recording, etc.
• MP4 motion pictures with a [Rec Quality] size of [FHD], [HD] or [VGA]:
Recording stops when the continuous recording time exceeds 29 minutes and 59 seconds or
the file size exceeds 4 GB.
– Since the file size becomes larger with [FHD], recording with [FHD] will stop before
29 minutes 59 seconds.
• MP4 motion pictures with a [Rec Quality] size of [4K]:
Recording stops when the continuous recording time exceeds 29 minutes and 59 seconds.
(You can continue recording without interruption even if the file size exceeds 4 GB, but the
motion picture file will be divided and recorded/played back separately.)
∫ Setting the format, size and recording frame rate
When [AVCHD] is selected
¢ AVCHD Progressive
> [Motion Picture] > [Rec Format]
[AVCHD] This data format is suitable for when playing back on a high-definition TV, etc.
[MP4] This data format is suitable for when playing back on a PC, etc.
> [Motion Picture] > [Rec Quality]
Item Size
Recording frame
rate
Sensor output Bit rate
[FHD/28M/50p]
¢
1920k1080
50p 50 frames/second
28 Mbps
[FHD/17M/50i]
1920k1080
50i 50 frames/second
17 Mbps
[FHD/24M/25p]
1920k1080
50i 25 frames/second
24 Mbps
[FHD/24M/24p]
1920k1080 24p 24 frames/second 24 Mbps
MENU
MENU
DMC-G7KHWbody_GN-SQT0919_eng.book 34 ページ ２０１５年５月２８日 木曜日 午後２時３８分

Panasonic LUMIX DMC-G7 Specifications

General

Megapixel	16.00 MP
Camera type	MILC
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	16.84 MP
Image sensor size	- \
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4592 x 3448 pixels
Image sensor size (W x H)	17.3 x 13 mm
Still image resolution(s)	4592 x 3448, 3232 x 2424, 2272 x 1704, 1824 x 1368, 4592 x 3064, 3232 x 2160, 2272 x 1520, 1824 x 1216, 4592 x 2584, 3840 x 2160, 1920 x 1080, 1824 x 1024, 3424 x 3424, 2416 x 2416, 1712 x 1712, 1712 x 1712
Filter size	52 mm
Optical zoom	- x
Focal length range	14 - 42 mm
Maximum aperture number	22
Minimum aperture number	3.5
Number of diaphragm blades	7
Number of aspheric elements	1
Lens structure (elements/groups)	12/9
Maximum focal length (35mm film equiv)	84 mm
Minimum focal length (35mm film equiv)	28 mm
Auto focusing (AF) modes	Continuous Auto Focus, Flexible Spot Auto Focus, Multi Point Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic, Mechanical
Fastest camera shutter speed	1/25 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed	1/160 s
Flash range (wide)	- m
Flash exposure correction	±3EV (1/2; 1/3 EV step)
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Maximum video resolution	3840 x 2160 pixels
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	3:2
Vari-angle LCD display	-
Display resolution (numeric)	1040000 pixels
Viewfinder type	Electronic
USB version	2.0
HDMI connector type	Micro
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modes	Children, Night landscape, Night portrait, Panorama, Pet, Portrait, Sports, Sunset
Photo effects	Negative film, Vivid
White balance	Auto, Cloudy, Daylight, Flash, Incandescent, Shade
GPS (satellite)	No
Self-timer delay	2, 10 s
Power source type	Battery
Battery voltage	7.2 V
Battery capacity	1200 mAh
Battery life (CIPA standard)	360 shots
Product color	Black
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	77.4 mm
Width	124.9 mm
Height	86.2 mm
Weight	360 g
Weight (including battery)	410 g
