Others
- 210 -
Store the battery in a cool and dry place with a relatively stable temperature: (Recommended
temperature: 15 oC to 25 oC (59 oF to 77 oF), Recommended humidity: 40%RH to 60%RH)
Always remove the battery and the card from the camera.
If the battery is left inserted in the camera, it will discharge even if the camera is turned off. If
the battery continues to be left in the camera, it will discharge excessively and may become
unusable even if charged.
When storing the battery for a long period of time, we recommend charging it once a year.
Remove the battery from the camera and store it again after it has completely discharged.
We recommend storing the camera with a desiccant (silica gel) when you keep it in a closet or
a cabinet.
Check all the parts before taking pictures when you have not used the camera for a long
period of time.
Recorded data may be damaged or lost if the camera breaks down due to inappropriate
handling. Panasonic will not be liable for any damage caused due to loss of recorded data.
When you use a tripod, make sure the tripod is stable when this unit is attached to it.
You may not be able to remove the card or the battery when using a tripod or unipod.
Make sure that the screw on the tripod or unipod is not at an angle when attaching or detaching
the camera. You may damage the screw on the camera if you use excessive force when
turning it. Also, the camera body and the rating label may be damaged or scratched if the
camera is attached too tightly to the tripod or unipod.
When using this unit with a large-diameter lens, the lens may come into contact with the
pedestal depending on the tripod/unipod. Tightening the screw with the lens and pedestal in
contact with each other may damage this unit or the lens. Therefore it is recommended to
attach the tripod adaptor (DMW-TA1; optional) before mounting on the tripod/unipod.
Read the operating instructions for the tripod or unipod carefully.
If you attach a heavy interchangeable lens (more than about 1 kg/35.3 oz) to the camera body,
do not carry the camera by the shoulder strap. Hold the camera and the lens when carrying
them.
When not using the camera for a long period of time
About the picture data
About tripods or unipods
About the shoulder strap

Table of Contents

Other manuals for Panasonic Lumix DMC-GX1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-GX1 and is the answer not in the manual?

Panasonic Lumix DMC-GX1 Specifications

General IconGeneral
Megapixel16 MP
Camera typeMILC
Sensor typeLive MOS
Image stabilizerYes
Total megapixels16.68 MP
Image sensor size- \
Image formats supportedEXIF, JPG, MPO, RAW
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4592 x 3448 pixels
Image sensor size (W x H)17.3 x 13 mm
Image stabilizer locationLens
Still image resolution(s)3232x2424, 2272x1704, 1824x1368, 4576x3056, 3232x2160, 2272x1520, 1824x1216, 4576x2576, 3232x1824, 1920x1080, 1824x1024, 3424x3423, 2416x2416, 1712x1712
Filter size52 mm
Digital zoom4 x
Optical zoom- x
Focal length range14 - 42 mm
Lens mount interfaceMicro Four Thirds (MFT)
Maximum aperture number5.6
Minimum aperture number3.5
Number of diaphragm blades7
Number of aspheric elements1
Lens structure (elements/groups)12/9
Maximum focal length (35mm film equiv)84 mm
Minimum focal length (35mm film equiv)28 mm
Focus adjustmentAuto/Manual
Auto Focus (AF) points23
Auto focusing (AF) modesContinuous Auto Focus, Flexible Spot Auto Focus, Single Auto Focus, Tracking Auto Focus
Closest focusing distance0.2 m
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity160, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modesAperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)12800
ISO sensitivity (min)160
Light exposure controlProgram AE
Light exposure correction± 5EV (1/3EV step)
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed60 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed1/160 s
Shoe mounting point typeHot shoe
Flash exposure correction±2EV (1/3 EV step)
Power source typeBattery
Maximum magnification0.34 x
Video resolutions640 x 480, 720 x 576, 1280 x 720, 1920 x 1080 pixels
Video formats supportedAVCHD, MP4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Audio systemMono
Audio formats supportedAAC, LPCM
Internal memory- MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Display resolution (numeric)460000 pixels
Magnification0.17 x
USB version2.0
HDMI connector typeMini
Product colorBlack, Silver
Scene modesChildren, Night portrait, Party (indoor), Portrait, Sports, Sunset
Image editingCrop, Resizing, Rotating
Photo effectsSepia
White balanceAuto, Cloudy, Daylight, Flash, Incandescent, Shade
Shooting modesMovie, Scene
Camera playbackMovie, Single image, Slide show, Thumbnails
Self-timer delay2, 10 s
Camera file systemDCF, Exif 2.3
Battery typeH-PS14042
Battery voltage7.2 V
Battery capacity1010 mAh
Battery life (CIPA standard)310 shots
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 80 %
Cables includedUSB
Bundled softwarePHOTOfunSTUDIO 7.0 HD Edition\\r SILKYPIX Developer Studio 3.1 SE\\r LoiLoScope
Weight and Dimensions IconWeight and Dimensions
Depth39.4 mm
Width116.3 mm
Height67.8 mm
Weight318 g
Lens length63.6 mm
Lens diameter60.6 mm
Weight (including battery)413 g
