- 73 -
Basic
• If you set a different language by mistake, select [~] from the menu icons to set the desired
language.
• [–. –] is displayed as the lens firmware when the lens is not mounted.
• The folder number is updated and the file number starts from 0001.
• A folder number between 100 and 999 can be assigned.
The folder number should be reset before it reaches 999. We recommend formatting the card
(P73) after saving the data on a PC or elsewhere.
• To reset the folder number to 100, format the card first and then use this function to reset the
file number.
A reset screen for the folder number will then appear. Select [YES] to reset the folder number.
• When the [REC] Mode settings are reset, data registered with [FACE RECOG.] will also be
reset.
• When [SETUP]/[CUSTOM] menu settings are reset, the following settings are also reset. In
addition, [ROTATE DISP.] is set to [ON].
– The [WORLD TIME] setting
– The settings of [TRAVEL DATE] (departure date, return date, location)
– The birthday and name settings for [BABY1]/[BABY2] and [PET] in Scene Mode
• The folder number and the clock setting are not changed.
• Use a battery with sufficient battery power or the AC adaptor (optional) when formatting. Do not
turn the camera off during formatting.
• If the card has been formatted on a PC or other equipment, format it on the camera again.
• If the card cannot be formatted, please try another card before contacting your nearest Service
Center.
~ [LANGUAGE] Set the language displayed on the screen.
[VERSION DISP.]
This enables the firmware versions of the camera and lens to be
checked.
v [NO.RESET] Reset the file number of the next recording to 0001.
w [RESET]
The [REC] or [SETUP]/[CUSTOM] menu settings are reset to the
initial settings.
[FORMAT]
The card is formatted.
Formatting permanently deletes all data on your memory
card. Please be sure all pictures and motion pictures are
saved elsewhere before using this feature.
For Canadian assistance, please call:
1-800-99-LUMIX (1-800-995-8649) or
send e-mail to: lumixconcierge@ca.panasonic.com
For USA and Puerto Rico assistance, please call:
1-800-211-PANA(7262) or, contact us via the web at:
http://www.panasonic.com/contactinfo

Panasonic Lumix DMC-GX1 Specifications

General

Megapixel	16 MP
Camera type	MILC
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	16.68 MP
Image sensor size	- \
Image formats supported	EXIF, JPG, MPO, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4592 x 3448 pixels
Image sensor size (W x H)	17.3 x 13 mm
Image stabilizer location	Lens
Still image resolution(s)	3232x2424, 2272x1704, 1824x1368, 4576x3056, 3232x2160, 2272x1520, 1824x1216, 4576x2576, 3232x1824, 1920x1080, 1824x1024, 3424x3423, 2416x2416, 1712x1712
Filter size	52 mm
Digital zoom	4 x
Optical zoom	- x
Focal length range	14 - 42 mm
Lens mount interface	Micro Four Thirds (MFT)
Maximum aperture number	5.6
Minimum aperture number	3.5
Number of diaphragm blades	7
Number of aspheric elements	1
Lens structure (elements/groups)	12/9
Maximum focal length (35mm film equiv)	84 mm
Minimum focal length (35mm film equiv)	28 mm
Focus adjustment	Auto/Manual
Auto Focus (AF) points	23
Auto focusing (AF) modes	Continuous Auto Focus, Flexible Spot Auto Focus, Single Auto Focus, Tracking Auto Focus
Closest focusing distance	0.2 m
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	160, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	12800
ISO sensitivity (min)	160
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed	1/160 s
Shoe mounting point type	Hot shoe
Flash exposure correction	±2EV (1/3 EV step)
Power source type	Battery
Maximum magnification	0.34 x
Video resolutions	640 x 480, 720 x 576, 1280 x 720, 1920 x 1080 pixels
Video formats supported	AVCHD, MP4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Audio system	Mono
Audio formats supported	AAC, LPCM
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
Magnification	0.17 x
USB version	2.0
HDMI connector type	Mini
Product color	Black, Silver
Scene modes	Children, Night portrait, Party (indoor), Portrait, Sports, Sunset
Image editing	Crop, Resizing, Rotating
Photo effects	Sepia
White balance	Auto, Cloudy, Daylight, Flash, Incandescent, Shade
Shooting modes	Movie, Scene
Camera playback	Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 10 s
Camera file system	DCF, Exif 2.3
Battery type	H-PS14042
Battery voltage	7.2 V
Battery capacity	1010 mAh
Battery life (CIPA standard)	310 shots
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Cables included	USB
Bundled software	PHOTOfunSTUDIO 7.0 HD Edition\\r SILKYPIX Developer Studio 3.1 SE\\r LoiLoScope

Weight and Dimensions

Depth	39.4 mm
Width	116.3 mm
Height	67.8 mm
Weight	318 g
Lens length	63.6 mm
Lens diameter	60.6 mm
Weight (including battery)	413 g
