VQT3T96 (ENG)
48
Interchangeable Lens (H-FS014042)
“LUMIX G VARIO 14–42 mm/F3.5–5.6 ASPH./MEGA O.I.S.”
Focal length f=14 mm to 42 mm
(35 mm film camera equivalent: 28 mm to 84 mm)
Aperture type 7 diaphragm blades/circular aperture diaphragm
Aperture range F3.5 (Wide) to F5.6 (Tele)
Minimum aperture
value
F22
Lens construction 12 elements in 9 groups (1 aspherical lens)
In focus distance 0.3 m (0.99 feet) to ¶ (from the focus distance reference line)
Maximum image
magnification
0.16k (35 mm film camera equivalent: 0.32k)
Optical Image
Stabilizer
Available
[O.I.S.] switch None
(Setting of the [STABILIZER] is done in [REC] menu.)
Mount “Micro Four Thirds Mount”
Angle of view 75x (Wide) to 29x (Tele)
Filter diameter 52 mm (2.05 inch)
Max. diameter Approx. 60.6 mm (2.39 inch)
Overall length Approx. 63.6 mm (2.50 inch)
(from the tip of the lens to the base side of the lens mount)
Mass (weight) Approx. 165 g
/0.36 lb
VQT3T96~Body3_eng.fm 48 ページ ２０１１年１０月２０日 木曜日 午前９時３０分
To Next Page
