DMC-GX1EG-S vol.1
Ref.No. Part No. Part Name & Description Pcs Remarks Ref.No. Part No. Part Name & Description Pcs Remarks
401 VYC1015 DECORATION RING 1 (GX1W)
402 ----- LENS MAIN UNIT 1 (GX1W)
(NOT SUPPLIED) See "Notes"
403 VEJ2295 MOUNT CONTACT UNIT 1 (GX1W)
404 ----- REAR FRAME UNIT 1 (GX1W)
(NOT SUPPLIED)
405 VXQ1940 L MOUNT UNIT 1 (GX1W)
406 VDW2116 SHADING FRAME 1 (GX1W)
B401 XQN16+BJ4FN SCREW 1 (GX1W)
B402 XQN16+BJ4FN SCREW 1 (GX1W)
B403 XQN16+BJ4FN SCREW 1 (GX1W)
B404 XQN14+BJ3FN SCREW 1 (GX1W)
B405 XQN14+BJ3FN SCREW 1 (GX1W)
B406 XQN14+BJ4FNK SCREW 1 (GX1W)
B407 XQN14+BJ4FNK SCREW 1 (GX1W)
B408 XQN14+BJ4FNK SCREW 1 (GX1W)
B409 VHD1868 SCREW 1 (GX1W)
B410 XQN14+AJ3FN SCREW 1 (GX1W)
B411 XQN2+AJ5FN SCREW 1 (GX1W)
B412 XQN2+AJ5FN SCREW 1 (GX1W)
B413 XQN2+AJ5FN SCREW 1 (GX1W)
B414 VHD2246 SCREW 1 (GX1W)
B415 VHD2246 SCREW 1 (GX1W)
B416 VHD2246 SCREW 1 (GX1W)
S-14
