- 112 -
Others
Before cleaning the camera, remove the battery or disconnect the power plug from the
outlet. Then wipe the camera with a dry, soft cloth.
When the camera is soiled badly, it can be cleaned by wiping the dirt off with a wrung wet cloth, and
then with a dry cloth.
Do not use solvents such as benzine, thinner, alcohol, kitchen detergents, etc., to clean the camera,
since it may deteriorate the external case or the coating may peel off.
When using a chemical cloth, be sure to follow the accompanying instructions.
Do not press the LCD monitor with excessive force. Uneven colors may appear on the LCD monitor
and it may malfunction.
If the camera is cold when you turn it on, the picture on the LCD monitor will be slightly darker than
usual at first. However, the picture will return to normal brightness when the internal temperature of
the camera increases.
Do not press the lens with excessive force.
Do not leave the camera with the lens facing the sun, as rays of light from the sun may cause it to
malfunction. Also, be careful when placing the camera outside or near a window.
Cleaning
About the LCD monitor
Extremely high precision technology is employed to produce the LCD monitor screen.
However, there may be some dark or bright spots (red, blue, or green) on the screen. This is
not a malfunction. The LCD monitor screen has more than 99.99% effective pixels with a
mere 0.01% of the pixels inactive or always lit. The spots will not be recorded on pictures on
the built-in memory or a card.
About the Lens

Table of Contents

Other manuals for Panasonic Lumix DMC-SZ3

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-SZ3 and is the answer not in the manual?

Panasonic Lumix DMC-SZ3 Specifications

General IconGeneral
Megapixel16.1 MP
Camera typeCompact camera
Sensor typeCCD
Image stabilizerYes
Total megapixels16.6 MP
Image sensor size1/2.33 \
Image formats supportedEXIF, JPG
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution3456 x 3456 pixels
Still image resolution(s)640 x 480, \\r 2048 x 1536\\r 2560 x 1920\\r 3456 x 3456\\r 3648 x 2736\\r 4608 x 2592\\r 4608 x 3072\\r 4608 x 3456
Digital zoom4 x
Optical zoom10 x
Combined zoom20 x
Extra/Smart zoom22.5 x
Focal length range4.5 - 45 mm
Maximum aperture number5.9
Minimum aperture number3.1
Lens structure (elements/groups)9/7
Maximum focal length (35mm film equiv)250 mm
Minimum focal length (35mm film equiv)25 mm
Focus adjustmentAuto
Auto focusing (AF) modesContinuous Auto Focus
Macro focusing range (tele)1.5 - ∞ m
Macro focusing range (wide)0.05 - ∞ m
ISO sensitivity100, 200, 400, 800, 1600
ISO sensitivity (max)1600
ISO sensitivity (min)100
Light exposure controlProgram AE
Light exposure correction± 2EV (1/3EV step)
Fastest camera shutter speed1/1600 s
Slowest camera shutter speed8 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)1.5 - 2.1 m
Flash range (wide)0.6 - 4.1 m
Video resolutions320 x 240, 640 x 480, 1280 x 720 pixels
Motion JPEG frame rate24 fps
Video formats supportedM-JPEG
Maximum video resolution1280 x 720 pixels
Analog signal format systemNTSC, PAL
Resolution at capture speed640x480@30fps
Audio systemMono
Memory slots1
Internal memory90 MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal2.7 \
Display resolution (numeric)230000 pixels
HDMINo
USB version-
Product colorBlack
Scene modesChildren, Night portrait, Panorama, Pet, Portrait, Sports, Sunset
Photo effectsBlack&White, Sepia, Vivid
White balanceAuto, Cloudy, Daylight, Halogen, Incandescent, Shade
Self-timer delay2, 10 s
Camera file systemDCF, DPOF 1.1, Exif 2.3
On Screen Display (OSD) languagesCZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, POL, POR, SWE, TUR
Power source typeBattery
Accessories included8GB SDHC
Battery voltage3.6 V
Battery capacity690 mAh
Battery life (CIPA standard)250 shots
Cables includedUSB
Bundled softwarePHOTOfunSTUDIO 9.0 LE, Adobe Reader
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 80 %
Weight and Dimensions IconWeight and Dimensions
Depth21.9 mm
Width94.8 mm
Height55.8 mm
Weight111 g
Weight (including battery)126 g
