Panasonic Lumix DMC-SZ3 Owner's Manual

- 113 -
Others
The battery is a rechargeable lithium ion battery. Its ability to generate power comes
from the chemical reaction that takes place inside it. This reaction is susceptible to the
surrounding temperature and humidity. If the temperature is too high or too low, the
operating time of the battery will become shorter.
Always remove the battery after use.
•
Place the removed battery in a plastic bag, and store or carry away from metallic objects (clips, etc.).
If you drop the battery accidentally, check to see if the body of the battery and the
terminals are damaged.
•
Inserting a damaged battery in the camera will damage the camera.
Do not remove or damage the external label on the battery.
•
Using a battery with part or all of the external labal removed or using the one with a torn label may
result in malfunctions.
Bring charged spare batteries when going out.
•
Be aware that the operating time of the battery becomes shorter in low temperature conditions such
as at a ski resort.
• When you travel, do not forget to bring the AC adaptor (supplied) and USB connection cable
(supplied) so that you can charge the battery in the country that you are traveling in.
Dispose of unusable battery.
•
The battery has a limited life.
• Do not throw the battery into fire because it may cause an explosion.
• The unusable battery should be discarded in accordance with battery recycling laws. Call the RBRC
hotline at 1-800-822-8837 for information.
Do not allow battery terminals to come into contact with metal objects (such as
necklaces, hairpins, etc.).
•
This can cause short-circuiting or heat generation and you may be badly burned if you touch a
battery.
• If you use the AC adaptor (supplied) near a radio, the radio reception may be disturbed.
• Keep the AC adaptor (supplied) 1 m (3.3 feet) or further away from radios.
• The AC adaptor (supplied) may generate whirring sounds when it is being used. This is not a
malfunction.
• After use, be sure to disconnect the power supply device from the electrical outlet. (A very small
amount of current is consumed if it is left connected.)
Battery
AC adaptor (supplied)

Panasonic Lumix DMC-SZ3 Specifications

General

Megapixel	16.1 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Total megapixels	16.6 MP
Image sensor size	1/2.33 \
Image formats supported	EXIF, JPG
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	3456 x 3456 pixels
Still image resolution(s)	640 x 480, \\r 2048 x 1536\\r 2560 x 1920\\r 3456 x 3456\\r 3648 x 2736\\r 4608 x 2592\\r 4608 x 3072\\r 4608 x 3456
Digital zoom	4 x
Optical zoom	10 x
Combined zoom	20 x
Extra/Smart zoom	22.5 x
Focal length range	4.5 - 45 mm
Maximum aperture number	5.9
Minimum aperture number	3.1
Lens structure (elements/groups)	9/7
Maximum focal length (35mm film equiv)	250 mm
Minimum focal length (35mm film equiv)	25 mm
Focus adjustment	Auto
Auto focusing (AF) modes	Continuous Auto Focus
Macro focusing range (tele)	1.5 - ∞ m
Macro focusing range (wide)	0.05 - ∞ m
ISO sensitivity	100, 200, 400, 800, 1600
ISO sensitivity (max)	1600
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 2EV (1/3EV step)
Fastest camera shutter speed	1/1600 s
Slowest camera shutter speed	8 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	1.5 - 2.1 m
Flash range (wide)	0.6 - 4.1 m
Video resolutions	320 x 240, 640 x 480, 1280 x 720 pixels
Motion JPEG frame rate	24 fps
Video formats supported	M-JPEG
Maximum video resolution	1280 x 720 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	640x480@30fps
Audio system	Mono
Memory slots	1
Internal memory	90 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	2.7 \
Display resolution (numeric)	230000 pixels
HDMI	No
USB version	-
Product color	Black
Scene modes	Children, Night portrait, Panorama, Pet, Portrait, Sports, Sunset
Photo effects	Black&White, Sepia, Vivid
White balance	Auto, Cloudy, Daylight, Halogen, Incandescent, Shade
Self-timer delay	2, 10 s
Camera file system	DCF, DPOF 1.1, Exif 2.3
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, POL, POR, SWE, TUR
Power source type	Battery
Accessories included	8GB SDHC
Battery voltage	3.6 V
Battery capacity	690 mAh
Battery life (CIPA standard)	250 shots
Cables included	USB
Bundled software	PHOTOfunSTUDIO 9.0 LE, Adobe Reader
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	21.9 mm
Width	94.8 mm
Height	55.8 mm
Weight	111 g
Weight (including battery)	126 g
