Panasonic Lumix DMC-SZ3 User Manual

- 14 -
Preparation
∫ Recording still pictures
Recording conditions by CIPA standard
•
CIPA is an abbreviation of [Camera & Imaging Products Association].
• Temperature: 23 oC (73.4 oF)/Humidity: 50%RH when LCD monitor is on.
• Using a Panasonic SD Memory Card (32 MB).
• Using the supplied battery.
• Starting recording 30 seconds after the camera is turned on. (When the Optical Image Stabiliser
function is set to [ON].)
• Recording once every 30 seconds using full flash every second recording.
• Rotating the zoom lever from Tele to Wide or vice versa in every recording.
• Turning the camera off every 10 recordings and leaving it until the temperature of the battery
decreases.
The number of recordable pictures varies depending on the recording interval time. As
the recording interval time becomes longer, the number of recordable pictures
decreases. [For example, if you were to take one picture every two minutes, then the
number of pictures would be reduced to approximately one-quarter of the number of
pictures given above (based upon one picture taken every 30 seconds).]
∫ Recording motion pictures
When recording with picture quality set to [HD]
•
These times are for an ambient temperature of 23 oC (73.4 oF) and a humidity of 50%RH. Please be
aware that these times are approximate.
• Actual recordable time is the time available for recording when repeating actions such as turning this
unit on and off, starting/stopping recording, zoom operation, etc.
• Motion pictures can be recorded continuously for up to 15 minutes. Also, continuous recording
exceeding 2 GB is not possible.
Remaining time for continuous recording is displayed on the screen.
Approximate operating time and number of recordable pictures
Number of recordable
pictures
Approx. 250 pictures
By CIPA standard in Normal
Picture Mode
Recording time Approx. 125 min
Recordable time Approx. 90 min
Actual recordable time Approx. 45 min

Panasonic Lumix DMC-SZ3 Specifications

General

Megapixel	16.1 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Total megapixels	16.6 MP
Image sensor size	1/2.33 \
Image formats supported	EXIF, JPG
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	3456 x 3456 pixels
Still image resolution(s)	640 x 480, \\r 2048 x 1536\\r 2560 x 1920\\r 3456 x 3456\\r 3648 x 2736\\r 4608 x 2592\\r 4608 x 3072\\r 4608 x 3456
Digital zoom	4 x
Optical zoom	10 x
Combined zoom	20 x
Extra/Smart zoom	22.5 x
Focal length range	4.5 - 45 mm
Maximum aperture number	5.9
Minimum aperture number	3.1
Lens structure (elements/groups)	9/7
Maximum focal length (35mm film equiv)	250 mm
Minimum focal length (35mm film equiv)	25 mm
Focus adjustment	Auto
Auto focusing (AF) modes	Continuous Auto Focus
Macro focusing range (tele)	1.5 - ∞ m
Macro focusing range (wide)	0.05 - ∞ m
ISO sensitivity	100, 200, 400, 800, 1600
ISO sensitivity (max)	1600
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 2EV (1/3EV step)
Fastest camera shutter speed	1/1600 s
Slowest camera shutter speed	8 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	1.5 - 2.1 m
Flash range (wide)	0.6 - 4.1 m
Video resolutions	320 x 240, 640 x 480, 1280 x 720 pixels
Motion JPEG frame rate	24 fps
Video formats supported	M-JPEG
Maximum video resolution	1280 x 720 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	640x480@30fps
Audio system	Mono
Memory slots	1
Internal memory	90 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	2.7 \
Display resolution (numeric)	230000 pixels
HDMI	No
USB version	-
Product color	Black
Scene modes	Children, Night portrait, Panorama, Pet, Portrait, Sports, Sunset
Photo effects	Black&White, Sepia, Vivid
White balance	Auto, Cloudy, Daylight, Halogen, Incandescent, Shade
Self-timer delay	2, 10 s
Camera file system	DCF, DPOF 1.1, Exif 2.3
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, POL, POR, SWE, TUR
Power source type	Battery
Accessories included	8GB SDHC
Battery voltage	3.6 V
Battery capacity	690 mAh
Battery life (CIPA standard)	250 shots
Cables included	USB
Bundled software	PHOTOfunSTUDIO 9.0 LE, Adobe Reader
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	21.9 mm
Width	94.8 mm
Height	55.8 mm
Weight	111 g
Weight (including battery)	126 g
