Before Use
Names and Functions of Main Parts
1Flash (P48)
2 Lens (P5, 112)
3 Self-timer indicator (P52)
AF Assist Lamp (P76)
4 LCD monitor (P44, 109, 112)
5 [MENU/SET] button (P37)
6[(] (Playback) button (P32)
7 [ ] (Delete/Cancel) button (P36)
8 [MODE] button (P23, 80)
9 Charging lamp (P11)
10 Speaker (P40)
•
Be careful not to cover the speaker with your
finger. Doing so may make sound difficult to
hear.
11 Motion picture button (P30)
12 Cursor buttons
A: 3/Exposure compensation (P53)
B: 4/[DISP.] (P44)
C: 2/Self-timer (P52)
D: 1/Flash setting (P48)
In these operating instructions, the cursor buttons are described as shown in the figure
below or described with 3/4/2/1.
e.g.: When you press the 4 (down) button
or Press 4
