- 51 -
Recording
The available flash range
The available flash range is an approximation.
Shutter speed for each flash setting
¢1 The shutter speed changes depending on the [Stabilizer] setting.
¢2 When [ ] in [Sensitivity] is set.
¢1, 2: The shutter speed becomes a maximum of 1 second in the following cases.
When the Optical Image Stabiliser is set to [OFF].
When the camera has determined that there is very little jitter when the Optical Image Stabiliser is
set to [ON].
In Intelligent Auto Mode, shutter speed changes depending on the identified scene.
In Scene Mode, shutter speed will be different from the above table.
If you bring the Flash too close to an object, the object may be distorted or discoloured by the heat or
lighting from the Flash.
Recording a subject from too close, or without sufficient flash will not provide the appropriate level of
exposure, and may result in a picture that is too white or dark.
When the Flash is being charged, the Flash icon blinks red, and you cannot take a picture even
when you press the shutter button fully.
If recording a subject without sufficient flash, the White Balance may not be properly adjusted.
The effects of the flash may not be adequately achieved under the following conditions.
When [Burst] is set to [ ]
When the shutter speed is too fast
It may take time to charge the Flash if you repeatedly take pictures. Take a picture after the access
indication disappears.
The Red-Eye Reduction effect differs between people. Also, if the subject is far away from the
camera or was not looking at the first Flash, the effect may not be evident.
Wide Tele
In [ ] in
[Sensitivity]
60 cm (2.0 feet) to 4.1 m (13 feet) 1.5 m (4.9 feet) to 2.1 m (6.9 feet)
Flash setting Shutter speed (Sec.) Flash setting Shutter speed (Sec.)
1/60 to 1/1600
1 or 1/8 to 1/1600
¢1
1 or 1/4 to 1/1600
¢2
‰Œ

Table of Contents

Other manuals for Panasonic Lumix DMC-SZ3

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-SZ3 and is the answer not in the manual?

Panasonic Lumix DMC-SZ3 Specifications

General IconGeneral
Megapixel16.1 MP
Camera typeCompact camera
Sensor typeCCD
Image stabilizerYes
Total megapixels16.6 MP
Image sensor size1/2.33 \
Image formats supportedEXIF, JPG
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution3456 x 3456 pixels
Still image resolution(s)640 x 480, \\r 2048 x 1536\\r 2560 x 1920\\r 3456 x 3456\\r 3648 x 2736\\r 4608 x 2592\\r 4608 x 3072\\r 4608 x 3456
Digital zoom4 x
Optical zoom10 x
Combined zoom20 x
Extra/Smart zoom22.5 x
Focal length range4.5 - 45 mm
Maximum aperture number5.9
Minimum aperture number3.1
Lens structure (elements/groups)9/7
Maximum focal length (35mm film equiv)250 mm
Minimum focal length (35mm film equiv)25 mm
Focus adjustmentAuto
Auto focusing (AF) modesContinuous Auto Focus
Macro focusing range (tele)1.5 - ∞ m
Macro focusing range (wide)0.05 - ∞ m
ISO sensitivity100, 200, 400, 800, 1600
ISO sensitivity (max)1600
ISO sensitivity (min)100
Light exposure controlProgram AE
Light exposure correction± 2EV (1/3EV step)
Fastest camera shutter speed1/1600 s
Slowest camera shutter speed8 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)1.5 - 2.1 m
Flash range (wide)0.6 - 4.1 m
Video resolutions320 x 240, 640 x 480, 1280 x 720 pixels
Motion JPEG frame rate24 fps
Video formats supportedM-JPEG
Maximum video resolution1280 x 720 pixels
Analog signal format systemNTSC, PAL
Resolution at capture speed640x480@30fps
Audio systemMono
Memory slots1
Internal memory90 MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal2.7 \
Display resolution (numeric)230000 pixels
HDMINo
USB version-
Product colorBlack
Scene modesChildren, Night portrait, Panorama, Pet, Portrait, Sports, Sunset
Photo effectsBlack&White, Sepia, Vivid
White balanceAuto, Cloudy, Daylight, Halogen, Incandescent, Shade
Self-timer delay2, 10 s
Camera file systemDCF, DPOF 1.1, Exif 2.3
On Screen Display (OSD) languagesCZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, POL, POR, SWE, TUR
Power source typeBattery
Accessories included8GB SDHC
Battery voltage3.6 V
Battery capacity690 mAh
Battery life (CIPA standard)250 shots
Cables includedUSB
Bundled softwarePHOTOfunSTUDIO 9.0 LE, Adobe Reader
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 80 %
Weight and Dimensions IconWeight and Dimensions
Depth21.9 mm
Width94.8 mm
Height55.8 mm
Weight111 g
Weight (including battery)126 g
