- 155 -
Connecting to other equipment
Preparations: Check the [HDMI MODE]. (P40)
Turn this unit and the TV off.
1 HDMI socket
2 TV with HDMI socket
3 HDMI mini (C type)
A Align the marks, and insert.
B HDMI mini cable (optional)
•
Check the direction of the terminals and plug in/out straight holding onto the plug. (It may result
in malfunction if the connectors of the cable are bent out of shape or plugged in the wrong
direction.)
Connect the HDMI mini cable B (optional) to the HDMI input socket
on the TV.
Connect the HDMI mini cable to the [HDMI] socket on the camera.
Turn the TV on and switch to HDMI input.
Turn the camera on and then press [(].
• Normal playback is displayed automatically when the power is turned on by pressing
and holding the [
(] button.
• When [VIERA Link] (P40) is set to [ON] and the camera is connected to a TV supporting
VIERA Link, input of the TV will be switched automatically and Playback screen will be
displayed (P157).
(Except for Clipboard Mode)
To Next Page
